Fibre Patch Lead SC/SC Duplex OM4 50U | 30m Length | Low Insertion Loss | Aqua LSZH Jacket | @Pack by Repelec
The Fibre Patch Lead SC/SC Duplex OM4 50U is designed for high-speed data transmission, featuring a 30m length and low insertion loss for optimal performance. Ideal for data centres and enterprise networking, this multimode fibre cable ensures secure connections with its SC to SC duplex connectors and LSZH jacket for enhanced safety.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Fibre Patch Lead SC/SC Duplex OM4 50U | 30m Length | Low Insertion Loss | Aqua LSZH Jacket | @Pack by Repelec
Brand: Repelec
SKU: DYNFL-SCSCOM4-30
Alternatively Known As: OM4 Fibre Patch Lead, SC to SC Duplex Fibre Cable, 30m Multimode Fibre Optic Patch Cord, OM4 50/125 SC-SC Cable
Technical Specifications
- Connector Type: SC to SC Duplex
- Fibre Type: OM4 50/125µm multimode
- Length: 30 metres
- Jacket Material: LSZH (Low Smoke Zero Halogen)
- Insertion Loss: ≤0.3dB
- Return Loss: ≥30dB
- Operating Temperature: -20°C to +70°C
- Colour: Aqua
- Dimensions (H x L x W): 10mm x 30000mm x 5mm
- Weight: 0.25 kg
Key Features
- 30 metre length for extended reach
- OM4 50/125µm multimode fibre for high bandwidth applications
- SC to SC duplex connectors for secure and reliable connections
- Low insertion loss and high return loss
- LSZH (Low Smoke Zero Halogen) jacket for enhanced safety
Professional Installation Requirements
- Installation by a qualified network technician is recommended to ensure optimal performance and compliance with network standards.
Applications
- Data centres
- Telecommunications rooms
- Enterprise networking
- High-speed LAN and SAN connections
- Server-to-switch connections
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- LSZH jacket reduces toxic emissions in case of fire
- Supports high-speed data transmission, enabling efficient network infrastructure
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Repelec SC/SC Duplex OM4 50U 30m Fibre Patch Lead is available for immediate purchase. Ideal for high-speed data centre, enterprise, and telecommunications applications.
