Flat Head Screw ISO 7045 | H Cross Recess | Zinc Plated Blue Passivated | M3x16 | @Pack of 50 | by Wurth
Flat head screw ISO 7045 with H cross recess and zinc plated blue passivated surface is perfect for general mechanical fastening and electronics assembly. Designed for moderate strength with a property class of 4.8, this screw ensures secure fastening in automotive components and industrial machinery. RoHS-compliant, it promotes environmental safety while providing durability and corrosion resistance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Flat Head Screw ISO 7045 | H Cross Recess | Zinc Plated Blue Passivated | M3x16 | @Pack of 50 | by Wurth
Brand: Wurth
SKU: 5103003016
Alternatively Known As: Flat head cross recess screw, ISO 7045 pan head screw, zinc plated flat head screw, metric thread screw M3x16
Technical Specifications
- Thread type x nominal diameter: M3
- Length: 16 mm
- Head diameter: 5.6 mm
- Head height: 2.4 mm
- Standards: ISO 7045
- Material: Steel
- Property class: 4.8
- Surface: Zinc plated blue passivated
- RoHS-compliant: Yes
- Head type: Flat head
- Drive type: Crosshead
- Internal drive: H1
- Thread type: Metric thread
- Pitch: 0.5 mm
- Thread form: Standard metric thread
- Product class: A
- Dimensions (H x L x W): 2.4mm x 16mm x 5.6mm
- Weight: 0.01 kg
Key Features
- Complies with ISO 7045 standard replacing DIN 7985
- Flat head design with H cross recess for secure drive
- Steel material with zinc plated blue passivated surface for corrosion resistance
- Metric thread M3 with 0.5 mm pitch
- Property class 4.8 for moderate strength
- RoHS-compliant ensuring environmental safety
Professional Installation Requirements
- Installation by qualified personnel recommended to ensure correct torque and secure fastening.
Applications
- General mechanical fastening
- Electronics assembly
- Automotive components
- Industrial machinery
- Furniture assembly
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems for workplace safety in handling and installation
Environmental Benefits
- RoHS-compliant material reduces hazardous substances
- Zinc plating provides corrosion resistance extending product life and reducing waste
Warranty Information
Standard manufacturer warranty against defects applies.
Available Now
Wurth Flat Head Screw ISO 7045 M3x16 is available for immediate purchase, ideal for industrial, mechanical, and general fastening applications.
