Flat Head Screw ISO 7045 M3x8 | Zinc Plated Blue Passivated | H Cross Recess | @Pack of 50 | by Wurth
Flat head screw ISO 7045 M3x8 with zinc plated blue passivated surface and H cross recess is perfect for general mechanical fastening and electronics assembly. Designed for durability, this screw meets ISO standards and is RoHS-compliant, making it ideal for automotive repairs and industrial machinery applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Flat Head Screw ISO 7045 M3x8 | Zinc Plated Blue Passivated | H Cross Recess | @Pack of 50 | by Wurth
Brand: Wurth
SKU: 5103003008
Alternatively Known As: Flat head cross recess screw, ISO 7045 pan head screw, Zinc plated flat head screw M3x8, Metric flat head screw
Technical Specifications
- Thread type x nominal diameter: M3
- Length: 8 mm
- Head diameter: 5.6 mm
- Head height: 2.4 mm
- Standards: ISO 7045
- Material: Steel
- Property class: 4.8
- Surface: Zinc plated blue passivated
- RoHS-compliant: Yes
- Head type: Pan head
- Drive type: Crosshead
- Internal drive: H1
- Thread type: Metric thread
- Pitch: 0.5 mm
- Thread form: Standard metric thread
- Product class: A
- Dimensions (H x L x W): 2.4mm x 8mm x 5.6mm
- Weight: 0.005 kg
Key Features
- Complies with ISO 7045 standard replacing DIN 7985
- Flat head screw with H cross recess for secure drive
- Steel material with zinc plated blue passivated surface for corrosion resistance
- Metric thread M3 with 0.5 mm pitch
- Property class 4.8 ensuring good mechanical strength
- RoHS-compliant
Professional Installation Requirements
- Installation by a qualified technician or tradesperson is recommended to ensure proper fastening and safety.
Applications
- General mechanical fastening
- Electronics assembly
- Automotive repairs
- Industrial machinery
- Furniture assembly
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- RoHS-compliant ensuring reduced hazardous substances
- Zinc plating provides corrosion resistance extending product life and reducing waste
Warranty Information
Standard manufacturer warranty against defects applies.
Available Now
Wurth Flat Head Screw ISO 7045 M3x8 is available for immediate purchase, ideal for mechanical, automotive, and industrial fastening applications.
