Flat Plate Fitting 14mm 1-Hole Hot-Dip Galvanised Unistrut
Unistrut hot-dip galvanised 1-hole flat plate fitting, 14mm, for strut channel assemblies.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Material: Punch press formed plate steel
- Finish: Hot dipped galvanised to AS/NZS 4680
- Hole Diameter: 14mm for M12 bolts
- Hole Spacing: 21mm from end, 48mm on centre
- Width: 40mm
- Thickness: 6mm
- Mass: 6.6 kg per 100 pieces
- Dimensions (H x L x W): 16 mm x 100 mm x 50 mm
- Weight: 0.066 kg
Key Features
- Made from punch press formed plate steel
- Hot dipped galvanised finish to AS/NZS 4680 for corrosion resistance
- 14mm diameter holes designed for M12 x 24 hex head set screws and nuts
- Hole spacing: 21mm from end, 48mm on centre
- Thickness of 6mm and width of 40mm
Professional Installation Requirements
- Installation requires appropriate tools and hardware; professional installation recommended for structural applications to ensure safety and compliance.
Applications
- Structural connections in construction and building frameworks
- General purpose steel fittings for assembly of channels and frames
- Suitable for use with 41mm square members and M12 bolts
Standards & Compliance
- Complies with AS/NZS 4680 for Hot Dipped Galvanised Coatings on Fabricated Ferrous Articles
Environmental Benefits
- Hot dipped galvanised finish provides long-lasting corrosion protection reducing need for frequent replacements
- Steel is recyclable, supporting sustainable construction practices
Warranty Information
Warranty details not specified; standard manufacturer warranty applies.
Available Now
The Flat Plate Fitting Hot Dipped Galvanised with 14mm Hole is available now for immediate purchase. Ideal for structural and general steel fitting applications.
