Flat Plate Fitting | Hot Dipped Galvanised | 14mm Hole

SKU: P1064H

$2.00 List price: $2.60

+ −

30 Days Return Delivery Options

Flat plate fitting with hot dipped galvanised finish and 14mm hole size—ideal for structural applications. Built for durability, with 40mm width and versatile design for various configurations.

Description

Product Name/Title: Flat Plate Fitting | Hot Dipped Galvanised | 14mm Hole

SKU: P1064H

Alternatively Known As: Steel Flat Plate Connector, Galvanised Flat Plate Bracket, Structural Flat Plate Fitting, Hot Dip Galvanised Steel Plate

Technical Specifications

Material: Punch press formed plate steel
Finish: Hot dipped galvanised to AS/NZS 4680
Hole Diameter: 14mm for M12 bolts
Hole Spacing: 21mm from end, 48mm on centre
Width: 40mm
Thickness: 6mm
Mass: 6.6 kg per 100 pieces
Dimensions (H x L x W): n/a mm x n/a mm x 40mm
Weight: 0.066 kg

Key Features

Made from punch press formed plate steel
Hot dipped galvanised finish to AS/NZS 4680 for corrosion resistance
14mm diameter holes designed for M12 x 24 hex head set screws and nuts
Hole spacing: 21mm from end, 48mm on centre
Thickness of 6mm and width of 40mm

Professional Installation Requirements

Installation requires appropriate tools and hardware; professional installation recommended for structural applications to ensure safety and compliance.

Applications

Structural connections in construction and building frameworks
General purpose steel fittings for assembly of channels and frames
Suitable for use with 41mm square members and M12 bolts

Standards & Compliance

Complies with AS/NZS 4680 for Hot Dipped Galvanised Coatings on Fabricated Ferrous Articles

Environmental Benefits

Hot dipped galvanised finish provides long-lasting corrosion protection reducing need for frequent replacements
Steel is recyclable, supporting sustainable construction practices

Warranty Information

Warranty details not specified; standard manufacturer warranty applies.

Available Now

The Flat Plate Fitting Hot Dipped Galvanised with 14mm Hole is available now for immediate purchase. Ideal for structural and general steel fitting applications.
