FlexChain Guest Light Grid Sensor | Infrared Sender/Receiver | IP65 & IP67 Rated | by SICK
The FlexChain Guest Light Grid Sensor is designed for industrial automation, featuring a sender/receiver light grid system with a PinPoint LED infrared light source. With an operating range of up to 15 meters and robust IP65/IP67 protection, this sensor is perfect for object detection, machine guarding, and access control applications, ensuring safety and efficiency in various environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Device version: FlexChain Guest
- Sensor principle: Sender/receiver light grid system
- Light source: PinPoint LED, Infrared light
- Light spot size at 12 m distance: Ø 375 mm
- Wavelength: 850 nm
- Supply voltage: 12 V via FlexChain host
- Adjustment: Cable sensitivity via FlexChain host
- Connection type: Male connector M8, 4-pin; Cable with female connector M8, 4-pin, 0.15 m
- Housing material: Plastic (ABS)
- Enclosure rating: IP65, IP67
- Protection class: III
- Operating range: 15 m
- Shock resistance: Single shocks 30 g, 11 ms; Continuous shocks 25 g, 6 ms
- Vibration resistance: Sinusoidal oscillation 20-2,000 Hz, 10 g
- EMC: EN 61000-6-2, EN 61000-6-3
- Ambient light immunity: Direct 40,000 lx
- Operating temperature: -25 °C to +55 °C
- Storage temperature: -25 °C to +70 °C
- Dimensions (H x L x W): 31.5mm x 21mm x 12mm
- Weight: 0.1 kg
Key Features
- Sender/receiver light grid system
- PinPoint LED infrared light source
- Operating range up to 15 meters
- Compact housing with IP65 and IP67 protection
- Shock and vibration resistant
- EMC compliant with EN 61000-6-2 and EN 61000-6-3
- Photobiological safety certified (IEC EN 62471)
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper integration with FlexChain host systems and compliance with safety standards.
Applications
- Industrial automation and safety systems
- Object detection and presence sensing
- Machine guarding and access control
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Low power consumption with 12 V supply via FlexChain host
- Durable plastic ABS housing reduces material waste
- Long operational life reduces replacement frequency
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK GSE6-CC021K00 FlexChain Guest Light Grid Sensor is available for immediate purchase, ideal for industrial automation and safety applications.
