Flexible Metal Conduit Zero Halogen | 63mm Diameter | Low Smoke & Flame Retardant | @Each by Wattmaster

BRAND: Wattmaster
SKU: ZHUA200-15
$5,693.90 List price: $6,891.60
+ −
30 Days Return Delivery Options
Flexible Metal Conduit Zero Halogen is designed for superior cable protection in restricted ventilation areas. With a durable 63mm diameter and low smoke, flame retardant properties, it’s perfect for industrial and commercial electrical installations. This conduit is IP67 rated when installed with approved connectors, ensuring safety in extreme temperature applications and direct burial scenarios.

Product Name/Title: Flexible Metal Conduit Zero Halogen | 63mm Diameter | Low Smoke & Flame Retardant | @Each by Wattmaster

Brand: Wattmaster

SKU: ZHUA200-15

Alternatively Known As: Zero Halogen Flexible Metal Conduit, Low Smoke Flexible Conduit, Anaconda ZHUA Conduit, Metal Cable Conduit, Flame Retardant Flexible Conduit

Technical Specifications
  • Diameter: 63mm
  • Length: 15 meters
  • Material: Hot dipped zinc galvanized steel core with TPU jacket
  • Jacket Properties: Zero halogen, low smoke, flame retardant, sunlight resistant, heat, oil and chemical resistant
  • Protection Rating: IP67 when installed with approved connectors
  • Compliance: UL Standard 360 File No. E18917
  • Suitable for extreme temperature applications
  • Approved for direct burial and both exposed and concealed locations
  • Dimensions (H x L x W): 63mm x 15000mm x 63mm
  • Weight: 4.5 kg
Key Features
  • Provides cable protection for restricted or self-contained ventilation areas
  • Complies with UL Standard 360 File No. E18917
  • Dust and liquid tight protection with IP67 rating when installed with approved connectors
  • Constructed of continuously interlocked hot dipped zinc galvanized steel core for exceptional crush and corrosion resistance
  • Durable, sunlight resistant, flame retardant, low smoke and zero halogen TPU jacket resistant to heat, oil, and chemical breakdown
  • Designed for extreme temperature applications
  • Meets demands of higher temperature rated conductors
  • Approved for both exposed and concealed locations
  • Approved for direct burial
Professional Installation Requirements
  • Installation should be performed by a qualified electrician to ensure compliance with electrical safety standards and proper sealing for IP67 rating.
Applications
  • Cable protection in restricted or self-contained ventilation areas
  • Suitable for exposed and concealed electrical installations
  • Direct burial applications
  • Environments requiring zero halogen and low smoke emission conduits
  • Industrial and commercial electrical wiring protection
Standards & Compliance
  • Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
  • Zero halogen and low smoke emissions reduce toxic gas release during fire, enhancing safety and environmental protection
  • Durable construction extends product life, reducing waste and replacement frequency
Warranty Information

Warranty terms vary; typically includes coverage against manufacturing defects. Please refer to Wattmaster's official warranty policy.

Available Now

The Wattmaster Flexible Metal Conduit Zero Halogen Low Smoke Anaconda ZHUA 63mm 15m Black is available for immediate purchase, ideal for industrial, commercial, and residential electrical conduit applications requiring high safety and durability.
