Flexible Stainless Steel Conduit 50mm 10m Grey Cabac
Cabac 50mm flexible stainless steel conduit (10m length) features interlocked flexible construction. Ideal for AS NZS 3000 compliant electrical installations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Material: 304-grade stainless steel core with PVC jacket
- Temperature Rating: -10 to +105 degrees Celsius
- Nominal Size: 50mm
- Trade Size: 1 1/2 inch
- Inner Diameter (ID): 40.3mm
- Outer Diameter (OD): 47.9mm
- Minimum Bend Radius: 180mm
- Length: 10 meters
- Dimensions (H x L x W): 50mm x 10000mm x 50mm
- Weight: 2.5 kg
Key Features
- Flexible 304-grade stainless steel core for superior corrosion resistance
- UV stabilised black PVC jacket providing chemical resistance and liquid tightness
- Non-flame propagating and resistant to most oils, acids, and vapours
- Compression resistant to heavy-duty rating of 1250 Newtons
- Operating temperature range from -10 to +105 degrees Celsius
- IP66 rating when used with CABFLX fittings
Professional Installation Requirements
- Professional installation by a qualified electrician or technician is recommended to ensure proper fitting and compliance with electrical standards.
Applications
- Indoor and outdoor cable installations requiring flexibility and corrosion resistance
- Harsh environments including coastal and marine applications
- Cable protection in industrial and commercial electrical installations
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable materials reduce the need for frequent replacements, minimizing waste
- Corrosion resistance extends product life in harsh environments
- UV stabilised PVC jacket reduces degradation from sunlight exposure
Warranty Information
Standard manufacturer warranty applies. Please refer to Cabac warranty terms for details.
Available Now
The Cabac CONDUIT CSS SS304 PVC NC50 X 10M BLACK is available now for immediate purchase. Ideal for industrial, commercial, and marine cable protection applications.
