Flexible Stainless Steel Conduit 63mm 10m Grey Cabac

BRAND: CABAC
SKU: CSS63BK
$1,548.80 List price: $2,065.10
1 ROL ($1,548.80 per ROL)
+ −
30 Days Return Electricians Unlock Trade Access
Cabac 63mm flexible stainless steel conduit (10m length) features interlocked flexible construction. Ideal for AS NZS 3000 compliant electrical installations.
Technical Specifications
  • Material: 304-grade stainless steel core with PVC jacket
  • Temperature Rating: -10 to +105 degrees Celsius
  • Nominal Size: 63mm
  • Trade Size: 2 inch
  • Inner Diameter (ID): 51.6mm
  • Outer Diameter (OD): 59.9mm
  • Minimum Bend Radius: 180mm
  • Length: 10 meters
  • Dimensions (H x L x W): 63mm x 10000mm x 63mm
  • Weight: 3.5 kg
Key Features
  • Flexible 304-grade stainless steel core for superior corrosion resistance
  • UV stabilised black PVC jacket providing liquid tight protection
  • Non-flame propagating and resistant to most oils, acids, and vapours
  • Compression resistant to HD rating of 1250 Newtons
  • Operating temperature range from -10 to +105 degrees Celsius
  • IP66 rating with CABFLX fittings
Professional Installation Requirements
  • Installation should be performed by a qualified professional to ensure compliance with electrical standards and proper mechanical protection.
Applications
  • Indoor and outdoor cable installations requiring corrosion resistance
  • Harsh environments with exposure to oils, acids, and vapours
  • Flexible conduit applications needing mechanical and environmental protection
Standards & Compliance
  • Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
  • Durable materials reduce the need for frequent replacements, minimizing waste
  • Corrosion resistance extends product life in harsh environments
  • UV stabilised PVC jacket reduces degradation from sunlight exposure
Warranty Information

Standard manufacturer warranty applies. Please refer to Cabac warranty terms for details.

Available Now

The Cabac CONDUIT CSS SS304 PVC NC63 X 10M BLACK is available for immediate purchase, ideal for cable protection in harsh indoor and outdoor environments.
