Flush Door Housing 14 Inch Adjustable Wall Thickness Ness
Ness flush door housing features 14 Inch size, adjustable wall thickness and a locking hinged door. Ideal for alarm system enclosures.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Ness Flush-Mount Alarm Enclosure, 14 Inch Security Panel Housing, Adjustable Wall Thickness Housing
Technical Specifications
- Product Code: 101-271FD
- Compatible Housing: Ness SWB14 14 inch metal housing, SKU 101-500
- Minimum Rough Opening: 361.95 W x 361.95 H x 88.90 D mm
- Door Type: Locking, removable, hinged door
- Wall Fitment: Adjustable for varying wall finish thickness
- Door Overhang: Approximately 14.73 mm beyond box edges
- Construction: Powder-coated metal enclosure component
- Mounting Type: Flush mount for hollow stud walls
- Installation Requirement: Requires Ness 101-500 14 inch metal housing
- Dimensions (H x L x W): 361.95mm x 361.95mm x 88.9mm
- Weight: 4 kg
Key Features
- Converts the Ness SWB14 housing to a flush-mount enclosure
- Suitable for hollow stud wall installation
- Adjustable to accommodate different wall finish thicknesses
- Locking hinged door helps restrict access to enclosed equipment
- Removable door simplifies installation and servicing
- Door overhang conceals uneven plasterboard or wallboard cut-outs
- Designed for alarm system control panels and related equipment
Applications
- Flush-mounted alarm system control panel enclosures
- Ness M1 control system installations
- Residential security alarm systems
- Commercial security and structured wiring installations
- Hollow-wall security equipment cabinets
Standards & Compliance
- Applicable to intruder alarm system installations designed and installed in accordance with AS/NZS 2201.1:2007; the manufacturer does not state that this enclosure alone is independently certified to the standard.
Environmental Benefits
- Metal construction can be recycled at end of service life
- Durable enclosure design supports long service life and reduces replacement waste
- Flush installation protects housed alarm equipment and may help extend component service life
Warranty Information
Ness manufactured or supplied products are covered by a 3-year warranty from the date of purchase, subject to Ness warranty terms and conditions.
Available Now
Available through Ness Corporation and authorised Australian security, automation and electrical distributors.
