Free Wheeling Diode 24-250VAC | Voltage Spike Suppression | Compact Design | by Clipsal
The Free Wheeling Diode 24-250VAC is designed to suppress voltage spikes in control circuits, making it ideal for industrial and commercial automation panels. With a wide operating voltage range and compact design, it enhances protection for sensitive electronic components, ensuring reliable performance in various applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Free Wheeling Diode 24-250VAC | Voltage Spike Suppression | Compact Design | by Clipsal
Brand: Clipsal
SKU: SCHLAD4DDL
Alternatively Known As: Flyback Diode, Snubber Diode, Suppression Diode, Relay Protection Diode, Freewheeling Rectifier
Technical Specifications
- Operating Voltage: 24-250VAC
- Type: Free Wheeling Diode
- Application: Suppression of voltage spikes in control circuits
- Mounting: Panel or DIN rail (with appropriate holder)
- Compatible Devices: Relays, contactors, solenoids
- Dimensions (H x L x W): 20mm x 30mm x 10mm
- Weight: 0.1 kg
Key Features
- Suppresses voltage spikes generated by inductive loads
- Wide operating voltage range: 24-250VAC
- Enhances protection for sensitive electronic components
- Compact and easy to install
- Reliable performance for industrial and commercial applications
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure correct integration with control circuits and compliance with safety standards.
Applications
- Used in electrical control circuits to suppress voltage spikes
- Suitable for use with contactors and relays in automation panels
- Industrial control panels
- Building automation systems
Standards & Compliance
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Extends the lifespan of electrical components, reducing electronic waste
- Improves energy efficiency by minimizing power surges
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal Free Wheeling Diode 24-250VAC (SCHLAD4DDL) is available for immediate purchase. Ideal for industrial and commercial automation panels requiring reliable voltage spike suppression.
