Galvanised Steel Corrugated Conduit 63mm 10m Grey UV Resistant Cabac

BRAND: CABAC
SKU: SPL63/10M
$1,094.00 List price: $1,458.70
1 ROL ($1,094.00 per ROL)
Free pick up (over 25 kg or over 1 meter)
Contact us for delivery cost
30 Days Return Electricians Unlock Trade Access
Cabac 63mm galvanised steel corrugated conduit, 10m length. UV resistant for cable protection.
Technical Specifications
  • Material: Galvanised steel core with durable PVC cover
  • Temperature range: -20ºC to +105ºC suitable for static and dynamic applications
  • Ingress Protection: IP66, IP67, IP68 (10 bar 30 mins), IP69 with appropriate fittings
  • Certifications: BSI Kitemark KM-35161, Low voltage directive, UL Recognised E135398
  • Compliance: AS/NZS 2053.1:2001, AS/NZS 2053.8:1995
  • UV Resistance: Very high
  • Flexibility: Medium
  • Fire Safety: Self-extinguishing
  • Dimensions (H x L x W): 63mm x 10000mm x 63mm
  • Weight: 5 kg
Key Features
  • IP Rating: Up to IP68 & IP69 with appropriate fitting
  • Very high UV resistance ideal for external use in extreme conditions
  • Medium flexibility and medium fatigue life for adaptability
  • Self-extinguishing properties for enhanced fire safety
  • High mechanical strength for durability and long-lasting performance
  • High resistance to various chemicals ensuring reliability
Professional Installation Requirements
  • Installation should be performed by qualified personnel familiar with liquid-tight conduit systems and compliant with relevant safety standards.
Applications
  • Industry Processing: Food, Chemical, Feed, Beverages
  • Wood, Chemicals
  • OEM (Original Equipment Manufacturer): Automation, Machines & Panel Building
  • Utility: Power
  • Mining Equipment
  • Suitable for indoor/outdoor applications including marine and buildings
Standards & Compliance
  • AS/NZS 2053.1:2001
  • AS/NZS 2053.8:1995
Environmental Benefits
  • Durable construction reduces need for frequent replacement, minimizing waste
  • High chemical resistance prevents environmental contamination
  • UV resistance extends product life in outdoor applications
Warranty Information

Warranty details available upon request from manufacturer.

Available Now

The Cabac CONDUIT SPL Galvanised Steel PVC NC63X10M Black is available for immediate purchase, ideal for industrial, utility, and mining applications requiring durable liquid-tight conduit protection.
