GEFU Thread Rolling Screw | Taptite 2000 Flat Head | Hexalobular Drive | Self-Tapping | @Pack of 50 | by Wurth
The GEFU Thread Rolling Screw is designed for efficient fastening with its Taptite 2000 thread and hexalobular drive. Ideal for mechanical assemblies, these self-tapping screws form nut threads without cutting material, ensuring high clamping force and load-bearing capacity. Made from case-hardened steel with zinc plating, they are perfect for applications in sheet metal parts and comply with RoHS standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: GEFU Thread Rolling Screw | Taptite 2000 Flat Head | Hexalobular Drive | Self-Tapping | @Pack of 50 | by Wurth
Brand: Wurth
SKU: 20971306
Alternatively Known As: Taptite Screw, Thread Rolling Screw, Self-Tapping Screw, Hexalobular Drive Screw, TX10 Screw, DIN 7500-1 Screw
Technical Specifications
- Dimensions (H x L x W): 2.4mm x 6mm x 5.6mm
- Weight: 0.01 kg
Key Features
- Mechanical and functional properties in accordance with DIN 7500-1 (shape PE)
- Case-hardened steel with zinc plating and blue passivation (A2K) with slide coating
- Head dimensions according to ISO 14583
- Self-tapping screws form nut threads by displacing and strain-hardening material
- Eliminates thread cutting, resulting in cost savings
- Low rolling torques with greater thread flank overlap
- TRILOBULAR core diameter shape combined with radius profile of thread flanks
- High clamping force and load-bearing capacity
- Play-free and self-locking thread seating
- Formed thread corresponds to standard metric thread
- RoHS-compliant
Professional Installation Requirements
- Installation by trained personnel or professionals recommended to ensure proper thread forming and torque application.
Applications
- Used for fastening in cast blind holes, rim holes, drilled, lasered, and punched sheet metal parts
- Ideal for applications requiring self-tapping screws that form nut threads without cutting material
- Suitable for mechanical assemblies requiring high clamping force and load-bearing capacity
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Eliminates need for thread cutting, reducing manufacturing waste
- RoHS-compliant, ensuring reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to Wurth's warranty policy for details.
Available Now
The Wurth GEFU Thread Rolling Screw with Taptite 2000 Thread Flat Head TX10 M3x6 is available for immediate purchase. Ideal for mechanical fastening in metal assemblies requiring durable, self-tapping screws.
