GEFU Thread Rolling Screw | Taptite 2000 | Flat Head & Hexalobular Drive | @Pack of 50 | by Wurth
The GEFU thread rolling screw features a Taptite 2000 thread design with a flat head and hexalobular TX8 drive, making it ideal for mechanical fastening in automotive and metal fabrication applications. Crafted from case-hardened steel with zinc plating and blue passivation, these screws ensure high clamping force and load-bearing capacity while eliminating the need for thread cutting, reducing material waste.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: GEFU Thread Rolling Screw | Taptite 2000 | Flat Head & Hexalobular Drive | @Pack of 50 | by Wurth
Brand: Wurth
SKU: 209712508
Alternatively Known As: Taptite Screw, Thread Rolling Screw, Self-Tapping Screw, Hexalobular Drive Screw, TX8 Screw, Flat Head Screw
Technical Specifications
- Thread type x nominal diameter: M2.5
- Length: 8 mm
- Head diameter: 5 mm
- Head height: 2.1 mm
- Head type: Flat head
- Material: Steel, case-hardened
- Surface: Zinc plated with blue passivation (A2K) and slide coating
- Thread type: Metric thread
- Internal drive: TX8 (hexalobular)
- Guideline values for hole diameters: 2.3 mm
- Standards: DIN 7500-1
- RoHS-compliant: Yes
- Dimensions (H x L x W): 2.1mm x 8mm x 5mm
- Weight: 0.01 kg
Key Features
- Mechanical and functional properties in accordance with DIN 7500-1 (shape PE)
- Case-hardened steel with zinc plating and blue passivation (A2K) with slide coating
- Head dimensions according to ISO 14583
- Self-tapping screws form a nut thread without interrupting material structure
- Non-cutting thread formation with low rolling torques and high thread flank overlap
- TRILOBULAR core diameter shape combined with radius profile of thread flanks
- High clamping force and load-bearing capacity due to strain-hardened counter thread
- Protection against loss with play-free and self-locking thread seating
- Formed thread corresponds to standard metric thread allowing replacement with metric screws
Professional Installation Requirements
- Installation by trained personnel or professionals recommended to ensure proper thread formation and fastening performance.
Applications
- Used for fastening in cast blind holes, rim holes, and drilled, lasered, or punched sheet metal parts
- Ideal for mechanical and functional fastening applications requiring high clamping force and load-bearing capacity
- Suitable for use in automotive, machinery, and metal fabrication industries
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Eliminates need for thread cutting, reducing material waste
- RoHS-compliant, ensuring reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies. Please refer to Wurth warranty policy for details.
Available Now
Available for immediate purchase. Ideal for mechanical fastening in metal fabrication, automotive, and industrial applications.
