GEFU Thread Rolling Screw | Taptite 2000 Thread | Flat Head & Hexalobular Drive | @Pack of 50 | by Wurth
The GEFU Thread Rolling Screw is designed with Taptite 2000 thread technology, featuring a flat head and hexalobular drive for superior fastening. Ideal for mechanical applications requiring high clamping force, this pack of 50 screws is perfect for forming nut threads in various materials, ensuring a secure fit without cutting. Built from case-hardened zinc-plated steel, these screws offer durability and compliance with industry standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: GEFU Thread Rolling Screw | Taptite 2000 Thread | Flat Head & Hexalobular Drive | @Pack of 50 | by Wurth
Brand: Wurth
SKU: 209712512
Alternatively Known As: Taptite Screw, Thread Rolling Screw, Self-Tapping Screw, Hexalobular Drive Screw, TX8 Screw, Flat Head Screw M2.5x12
Technical Specifications
- Dimensions (H x L x W): 2.1mm x 12mm x 5mm
- Weight: 0.01 kg
Key Features
- Mechanical and functional properties in accordance with DIN 7500-1 (shape PE)
- Case-hardened zinc-plated steel with blue passivation (A2K) and slide coating
- Head dimensions according to ISO 14583
- Self-tapping screws form a nut thread without interrupting material structure
- Non-cutting thread formation with low rolling torques and high thread flank overlap
- TRILOBULAR core diameter shape combined with radius profile of thread flanks
- High clamping force and load-bearing capacity due to strain-hardened counter thread
- Protection against loss with play-free and self-locking thread seating
- Formed thread corresponds to a standard metric thread allowing replacement with metric screws
Professional Installation Requirements
- Installation by trained personnel or professionals recommended to ensure proper thread forming and fastening.
Applications
- Used for forming nut threads in cast blind holes, rim holes, and drilled, lasered, and punched sheet metal parts
- Ideal for mechanical fastening where high clamping force and load-bearing capacity are required
- Suitable for applications requiring self-tapping screws with strain-hardened counter threads
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Eliminates the need for thread cutting, reducing material waste
- RoHS-compliant, ensuring reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies. Please refer to Wurth's warranty policy for details.
Available Now
The Wurth GEFU Thread Rolling Screw with Taptite 2000 Thread Flat Head TX8 M2.5x12 is available for immediate purchase. Ideal for mechanical fastening in metal fabrication and assembly applications.
