GEFU Thread Rolling Screw | Taptite 2000 Thread | Flat Head & TX8 Drive | @Pack of 50 | by Wurth
The GEFU thread rolling screw features a Taptite 2000 thread and a flat head design, making it ideal for mechanical fastening in metal fabrication and assembly applications. With a robust TX8 hexalobular drive and case-hardened zinc-plated steel construction, this screw ensures high clamping force and load-bearing capacity, perfect for sheet metal parts and cast blind holes.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: GEFU Thread Rolling Screw | Taptite 2000 Thread | Flat Head & TX8 Drive | @Pack of 50 | by Wurth
Brand: Wurth
SKU: 209712505
Alternatively Known As: Taptite 2000 Screw, Thread Rolling Screw, Self-Tapping Screw M2.5x5, Hexalobular Drive Screw TX8, DIN 7500-1 Screw
Technical Specifications
- Thread type x nominal diameter: M2.5
- Length: 5 mm
- Head diameter: 5 mm
- Head height: 2.1 mm
- Head type: Flat head
- Material: Steel, case-hardened
- Surface: Zinc plated with blue passivation (A2K) and slide coating
- Thread type: Metric thread
- Internal drive: TX8 hexalobular
- Guideline hole diameter: 2.3 mm
- Standards: DIN 7500-1
- RoHS-compliant: Yes
- Dimensions (H x L x W): 2.1mm x 5mm x 5mm
- Weight: 0.005 kg
Key Features
- Mechanical and functional properties in accordance with DIN 7500-1 (shape PE)
- Case-hardened zinc-plated steel with blue passivation (A2K) and slide coating
- Head dimensions according to ISO 14583
- Self-tapping screws form a nut thread without interrupting material structure
- Non-cutting thread formation displaces and strain-hardens material
- Low rolling torques with greater thread flank overlap
- TRILOBULAR core diameter shape combined with radius profile of thread flanks
- High clamping force and load-bearing capacity
- Play-free and self-locking thread seating
- Standard metric thread compatibility
- RoHS-compliant
Professional Installation Requirements
- Installation by trained personnel or professionals recommended to ensure correct torque and thread engagement.
Applications
- Assembly of cast blind holes
- Sheet metal parts fastening
- Rim holes and drilled, lasered, punched metal parts
- Mechanical and functional fastening requiring self-tapping screws
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- RoHS-compliant material reduces hazardous substances
- Durable zinc plating extends product life and reduces replacement frequency
Warranty Information
Warranty against manufacturing defects as per Wurth standard terms and conditions.
Available Now
The Wurth GEFU thread rolling screw M2.5x5mm with Taptite 2000 thread and TX8 drive is available for immediate purchase. Ideal for mechanical fastening in metal fabrication and assembly applications.
