General Purpose Relay 10A 3CO | 110V DC Coil | Mechanical Indicator by NHP
General purpose relay with 10A nominal current and 3 changeover contacts—ideal for industrial automation and control panels. Built for reliable switching, with 110V DC coil and mechanical indicator for easy monitoring.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Finder 60 Series General Purpose Relay 10A 3CO 110V DC Coil with PB plus Mechanical Indicator
Brand: NHP
SKU: 6013110VDCRLY
Alternatively Known As: General Purpose Relay, Switching Relay, Panel Mount Relay
Technical Specifications
- Nominal Current: 10 A
- Nominal Voltage AC: 250 V
- Max Rated Operation Voltage (AC): 400 V
- Rated Switching Power at AC-1: 2500 VA
- Rated Switching Power at AC-15 (230 V): 500 VA
- Breaking Capacity at DC-1 (30 V): 10 A
- Breaking Capacity at DC-1 (110 V): 0.4 A
- Control Supply Voltage (DC): 110 V
- Electrical Life: 200,000 cycles
- Mechanical Life: 50,000,000 cycles
- Operating Temperature: -40 to 70 °C
- Dimensions (H x L x W): 36.4mm x 54.2mm x 32.5mm
- Weight: 0.1 kg
Key Features
- 10A nominal current with 3 changeover contacts.
- 110V DC coil with mechanical indicator.
- Plug-in connection for easy installation.
Professional Installation Requirements
- Professional installation by a qualified technician is recommended for optimal performance.
Applications
- Industrial: Automation systems, control panels
- Commercial: HVAC systems, lighting control
- General: Any application requiring reliable switching
Standards & Compliance
- Complies with relevant electrical safety standards.
Environmental Benefits
- Energy-efficient design reduces power consumption.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Finder 60 Series General Purpose Relay is available now for immediate purchase. Ideal for industrial and commercial applications requiring reliable switching.
