General Purpose Relay 10A 3CO | 6V AC Coil | Mechanical Indicator | Plug-In by NHP
General purpose relay with 10A nominal current and 3 changeover contacts—ideal for industrial automation and control panels. Built for reliable switching, with a mechanical indicator and plug-in connection for easy installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Finder 60 Series General Purpose Relay 10A 3CO 6V AC Coil with PB plus Mechanical Indicator
Brand: NHP
SKU: 60136VACRLY
Alternatively Known As: General Purpose Relay, Switching Relay, Panel Mount Relay
Technical Specifications
- Nominal Current: 10 A
- Nominal Voltage AC: 250 V
- Max Rated Operation Voltage: 400 V
- Rated Switching Power at AC 1: 2500 VA
- Rated Switching Power at AC 15 (230 V): 500 VA
- Breaking Capacity at DC 1 (30 V): 10 A
- Breaking Capacity at DC 1 (110 V): 0.4 A
- Control Supply Voltage: 6 V AC
- Electrical Life: 200,000 cycles
- Mechanical Life: 20,000,000 cycles
- Operating Temperature: -40 to 70 °C
- Dimensions (H x L x W): 36.4mm x 54.2mm x 32.5mm
- Weight: 0.1 kg
Key Features
- 10A nominal current with 3 changeover contacts.
- Mechanical indicator for operational status.
- Plug-in connection for easy installation.
Professional Installation Requirements
- Professional installation is recommended for optimal performance and safety.
Applications
- Industrial: Automation systems, control panels
- Commercial: HVAC systems, lighting control
- General: Any application requiring reliable switching
Standards & Compliance
- Complies with relevant Australian standards for electrical safety.
Environmental Benefits
- Energy-efficient design contributes to reduced power consumption.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Finder 60 Series General Purpose Relay 10A 3CO 6V AC Coil is available now for immediate purchase. Ideal for industrial and commercial applications.
