General Purpose Relay 2 Pole | 12A Current Rating | 24V AC Coil | by Allen-Bradley
The General Purpose Relay 2 Pole from Allen-Bradley features a 12A current rating and a 24V AC coil, making it ideal for industrial control systems and automation equipment. With push-to-test and manual override functions, plus an LED option for status indication, this relay ensures reliable performance in electrical switching applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Contact Configuration: 2 Pole
- Current Rating: 12 A
- Coil Voltage: 24 V AC
- Frequency: 50/60 Hz
- Terminal Type: Blade-style
- Features: Push-to-test, Manual override, LED option
- Dimensions (H x L x W): 60mm x 50mm x 45mm
- Weight: 0.2 kg
Key Features
- General purpose relay with square base
- Blade-style terminals for easy wiring
- 2 pole configuration
- Push-to-test and manual override functions
- LED option for status indication
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical standards and safety.
Applications
- Industrial control systems
- Automation equipment
- Electrical switching applications
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable design reduces need for frequent replacements, minimizing waste.
Warranty Information
Radwell 2-year warranty included; factory warranty does not apply.
Available Now
The Allen-Bradley 700HF32A2434 General Purpose Relay is available now for immediate purchase. Ideal for industrial and automation control applications.
