20 Port Gigabit Managed Network Switch | 16 PoE+ Ports | 2 RJ45 GbE & 2 SFP | Matchmaster
Gigabit managed network switch with 16 PoE+ ports and 2 RJ45 GbE ports—ideal for office networks. Built for high-speed connections, with flexible uplink options and advanced network management.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 20 Port Gigabit Managed Network Switch (16 PoE+ Ports, 2 RJ45 GbE Ports plus 2 SFP)
Brand: Matchmaster
SKU: 57MM-SW20P
Alternatively Known As: Managed PoE Switch, Gigabit Switch, Network Switch with PoE, 20 Port Switch
Technical Specifications
- Switching capacity: 40 Gbps
- Max PoE budget: 250W
- Layer Type: Layer 2
- Forwarding rate: 29.76Mpps
- Packet Buffer: 4.1 Mbit
- MAC address table: 8000
- Maximum VLAN Support: 16
- Power Consumption: ≤ 269W
- Operating Temperature: 0°C to 40°C
- Storage Temperature: -40°C to 70°C
- Operating Humidity: 10% to 90% RH
- Storage Humidity: 5% to 95% RH
- Port Surge: 4 kV
- Dimensions (H x L x W): 44mm x 223mm x 300mm
- Weight: 2.8 kg
Key Features
- 20 port managed network switch with 16 PoE+ ports.
- 2 RJ45 GbE ports and 2 SFP ports supporting up to 40Gbps switching capacity.
- 250W PoE budget providing up to 30W per PoE port.
- Smart networking features via free cloud service for remote management.
- IP camera recognition for efficient CCTV management.
- Supports port mirroring, loop protection, and cable detection.
Professional Installation Requirements
- Professional installation is recommended for optimal network performance.
Applications
- Ideal for enterprise networking, data centers, and smart building applications.
Standards & Compliance
- Complies with CE and RoHS standards.
Environmental Benefits
- Energy-saving features through automatic PoE power negotiation.
Warranty Information
3 years warranty against manufacturing defects.
Available Now
The Matchmaster 20 Port Gigabit Managed Network Switch is available now for immediate purchase. Ideal for enterprise networking and data center applications.
