Making Trade Life Easy!

Home/Electrical/Industrial/Industrial Outlets/Gland Bracket 3300V 425A 6P | IP55 Rated | Quick Release & Stainless Steel | Ausproof

Trade Discount 19%

PL QR 3300V 425A 6P Gland Bracket (0) 95-C 65-70-G (245.3)

Gland Bracket 3300V 425A 6P | IP55 Rated | Quick Release & Stainless Steel | Ausproof

BRAND: Ausproof

SKU: RS2645QR

$3,839.00 List price: $4,768.00

+ −

30 Days Return Delivery Options

Gland bracket with 3300V operating voltage and 425A current rating—ideal for mining and hazardous environments. Built for safety and durability, featuring quick release and stainless steel construction for reliable electrical connections.

Description

Product Name/Title: PL QR 3300V 425A 6P Gland Bracket (0) 95-C 65-70-G (245.3)

Brand: Ausproof

SKU: RS2645QR

Alternatively Known As: PL Range Receptacle, Ex-certified Gland Bracket, Quick Release Plug Connector, Mining Electrical Connector

Technical Specifications

Operating Voltage: 660V to 3300V
Current Rating: 300A to 425A
Material: Stainless Steel
Ingress Protection: IP55
Through Fault Current (Phase): 2 tests of 25.0kA for 0.2 seconds
Through Fault Current (Earth): 2 tests of 8.0kA for 0.2 seconds
AC High Voltage Withstand (Phase): 8.6kV for one minute
AC High Voltage Withstand (Pilot): 1.0kV for one minute
Temperature Rise: Rated for 300A and 425A
Weight: 10.7 kg (Receptacle), 9.0 kg (Plug)
Compliance: AS/NZS 1299, IEC 60079-0, IEC 60079-1
Dimensions (H x L x W): 200mm x 400mm x 300mm
Weight: 10.7 kg

Key Features

Quick Release
Single piece contacts to prevent hot joints
Easy termination
Easy flameproof repair
Full solid earth connectivity throughout product
Full phase to phase segregation with earth
Lightest Ex product on the market
Silicone Protection Cover
Stainless steel Hanging Plate for Back-to-Back (B2B) receptacles

Professional Installation Requirements

Installation and maintenance should be performed by qualified personnel trained in hazardous area electrical equipment to ensure compliance and safety.

Applications

Mining
Tunnelling
Commercial applications
Group 1 hazardous environments

Standards & Compliance

Complies with AS/NZS 1299 – Electrical Equipment for Explosive Atmospheres

Environmental Benefits

Durable stainless steel construction reduces need for frequent replacements.
Flameproof repairability reduces waste by allowing on-site repairs without full replacement.

Warranty Information

Warranty details available upon request from Ausproof, typically covering manufacturing defects.

Available Now

The Ausproof PL QR 3300V 425A 6P Gland Bracket is available now for immediate purchase. Ideal for mining, tunnelling, and hazardous commercial applications requiring robust, flameproof electrical connections.
