Glue Lined 4 Way Breakout Boot | -40°C to +100°C | UV Stabilised & Adhesive Lined | 3:1 Shrink Ratio by United Manufacturers Australia
Glue lined 4 way breakout boot designed for electrical insulation and protection, with a temperature range of -40°C to +100°C and a 3:1 shrink ratio. Ideal for industrial and commercial applications, it offers waterproof and UV resistant features for reliable performance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Glue Lined 4 Way Breakout Boot | -40°C to +100°C | UV Stabilised & Adhesive Lined | 3:1 Shrink Ratio by United Manufacturers Australia
Brand: United Manufacturers Australia
SKU: UMB430
Alternatively Known As: Heatshrink Breakout Boot, Glue Lined Cable Boot, 4 Way Heatshrink Boot, Cable Breakout Sleeve
Technical Specifications
- Type: 4 Way
- Size: 58.0mm - 26.0mm
- Fingers: 21.0mm - 7.0mm
- Pack Quantity: 1
- Temperature Range: -40°C to +100°C
- Shrink Ratio: 3:1
- UV Stabilised and Adhesive Lined
- Dimensions (H x L x W): 26mm x 100mm x 58mm
- Weight: 0.1 kg
Key Features
- Glue lined for quick and easy application
- Water tight and highly resistant to ultraviolet rays and various chemicals
- Adhesive lined and UV stabilised
- 3:1 shrink ratio
- Temperature range from -40°C to +100°C
Professional Installation Requirements
- Professional installation by a qualified electrician or technician is recommended to ensure proper application and sealing.
Applications
- Electrical insulation and protection for cable joints and terminations
- Industrial and commercial electrical installations requiring waterproof and UV resistant breakout boots
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable and long-lasting material reduces the need for frequent replacements
- Protects cables from environmental damage, reducing electronic waste
Warranty Information
Standard manufacturer warranty applies. Please refer to United Manufacturers Australia for specific warranty details.
Available Now
The Glue Lined 4way Break Out Boot by United Manufacturers Australia is available now for immediate purchase. Ideal for electrical insulation and protection in industrial and commercial applications.
