Product Name/Title: Allen-Bradley 800TQTH2G Green LED Pilot Light Unit
Brand: Allen-Bradley
SKU: 800TQTH2G
Alternatively Known As: Green LED Indicator Light, Pilot Lamp, Control Panel Indicator
Technical Specifications
- Operating Voltage: 12-130 VAC/DC
- Contact Block Operational Voltage: 600 VAC/DC
- Contact Configuration: 1 Normally Open (NO) / 1 Normally Closed (NC)
- Hole Diameter: 30.5 mm
- Lens Colour: Green
- Lamp Type: LED
- Push to Test Option: Yes
- Enclosure Rating: Metal Type 4/13
- Dimensions (H x L x W): 35mm x 40mm x 35mm
- Weight: 0.1 kg
Key Features
- Full voltage power module type
- Push to test option for easy functionality check
- Green LED lamp for clear indication
- 1 NO/1 NC contact configuration
- Metal Type 4/13 rated for harsh environments
- No finger safe guards
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical safety standards and proper integration into control systems.
Applications
- Industrial control panels
- Machinery status indication
- Electrical signaling in manufacturing environments
Standards & Compliance
- AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- LED technology reduces energy consumption compared to traditional incandescent pilot lights.
Warranty Information
Radwell 2-year warranty included; factory warranty does not apply.
Available Now
The Allen-Bradley 800TQTH2G Green LED Pilot Light Unit is available now for immediate purchase, ideal for industrial and manufacturing control panel applications.
