Halogen Free Blue Cable Duct 40x80 | ABS Material | Self-Extinguishing | Dust-Free Cutting | @Len of 1 | by Legrand
Halogen free blue cable duct 40x80 is designed for safe electrical installations, featuring durable ABS material and self-extinguishing properties. Ideal for public buildings, rolling stock, and IT environments, it ensures compliance with safety standards while allowing for smooth, dust-free wiring. The innovative design includes side and bottom cut-outs for easy installation and maintenance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Halogen Free Blue Cable Duct 40x80 | ABS Material | Self-Extinguishing | Dust-Free Cutting | @Len of 1 | by Legrand
Brand: Legrand
SKU: 636208
Alternatively Known As: Halogen Free Cable Duct, Blue Cable Trunking, ABS Cable Duct, Halogen-Free Wiring Duct
Technical Specifications
- Material: Acrylonitrile Butadiene Styrene (ABS)
- Cross-section: 40x80 mm
- Wiring capacity: 2717 mm²
- Color: Grey
- Distance of slots: 6.5 mm
- Slit width: 6 mm
- Type of side wall: Hole/slot punching
- Halogen free: Yes
- Self-extinguishing: Yes
- Flexible: No
- Type of fastening: Bottom perforation
- With cover: Yes
- Operating temperature: -5 to 60 °C
- Storage temperature: -25 to 60 °C
- Dimensions (H x L x W): 80mm x 2000mm x 40mm
- Weight: 1.2 kg
Key Features
- Halogen free, does not release halogenated gases in case of fire
- Hand-splitting cable duct with side and bottom cut-outs for dust-free and smooth cutting
- Retaining bossage keeps wires at the bottom and prevents pull-out during wiring
- Allows wiring on two levels
- T-junction capability between vertical and horizontal ducts without obstacles
- Cover installs easily by frontal-clicking or rotation without tools
- Ribbing on edges for label alignment
- Self-extinguishing material
Professional Installation Requirements
- Professional installation by qualified electricians is recommended to ensure compliance with electrical standards and safety.
Applications
- Electrical installations in buildings receiving public access
- Rolling stock applications such as trains and subways
- IT rooms and data centers requiring halogen-free cable management
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Halogen free material reduces toxic gas emissions during fire, enhancing safety and environmental protection
- Durable ABS construction extends product life and reduces waste
Warranty Information
Standard manufacturer warranty applies; please refer to Legrand for specific warranty details.
Available Now
Legrand Halogen Free Blue Cable Duct 40x80 is available for immediate purchase, ideal for electrical installations in public buildings, rolling stock, and IT environments.
