Trade Discount 20%
Halogen Free Blue Cable Duct 60x80 | ABS Material | Self-Extinguishing | Ideal for Public Installations | @Len of 1 | by Legrand
Halogen free blue cable duct 60x80 is designed for safe and efficient cable management in public buildings and IT environments. Made from durable ABS material, it features a self-extinguishing property, ensuring minimal toxic gas emissions in case of fire. With its innovative design, this cable duct allows for smooth cutting and easy installation, making it perfect for professional electricians and technicians.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Halogen Free Blue Cable Duct 60x80 | ABS Material | Self-Extinguishing | Ideal for Public Installations | @Len of 1 | by Legrand
Brand: Legrand
SKU: 636213
Alternatively Known As: Blue Cable Duct 60x80, Halogen Free Cable Raceway, Legrand Cable Trunking, ABS Cable Duct
Technical Specifications
- Material: Acrylonitrile Butadiene Styrene (ABS)
- Cross-section: 60x80 mm
- Usable cross section: 4216 mm²
- Color: Grey
- Operating temperature: -5 to 60 °C
- Storage temperature: -25 to 60 °C
- Distance of slots: 6.5 mm
- Slit width: 6 mm
- Type of side wall: Hole/slot punching
- Type of fastening: Bottom perforation
- Self-extinguishing: Yes
- Flexible: No
- With cover: Yes
- Dimensions (H x L x W): 80mm x 2000mm x 60mm
- Weight: 1.5 kg
Key Features
- Halogen free, does not release halogenated gases in case of fire
- Hand-splitting cable duct with side and bottom cut-outs for dust-free and smooth cutting
- Retaining bossage keeps wires and cables at the bottom and prevents pull-out during wiring
- Allows wiring on two levels
- T-junction possible between vertical and horizontal ducts without obstacle
- Cover easily installed by frontal-clicking or rotation, opening without tools
- Ribbing on edges for label alignment
- Self-extinguishing material
Professional Installation Requirements
- Professional installation by qualified electricians or technicians is recommended to ensure compliance with electrical safety standards and optimal cable management.
Applications
- Installations in buildings receiving public access
- Rolling stock such as trains and subways
- IT rooms and data centers
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Halogen free material reduces toxic gas emissions in case of fire
- Durable ABS construction extends product life and reduces waste
Warranty Information
Standard manufacturer warranty applies; please refer to Legrand for specific warranty details.
Available Now
Legrand Halogen Free Blue Cable Duct 60x80 is available for immediate purchase, ideal for electrical installations in public buildings, transport, and IT environments.
