Hawk 12W Single LED Security Spotlight | IP65 Rated | PIR Sensor | Tri-CCT Options | by atom
The Hawk 12W Single LED Security Spotlight is designed for outdoor security lighting, featuring an IP65 rating for weather resistance and a PIR sensor with an 8m detection range. With a high LED lifetime of 108,000 hours and tri-CCT options (Warm White, Cool White, DayLight), this spotlight is perfect for residential and commercial properties, ensuring reliable illumination when you need it most.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: LED Security Floodlight, PIR Sensor Security Light, Outdoor LED Spotlight, Motion Sensor Floodlight
Technical Specifications
- Total System Efficiency: 110 lm/W
- IP Rating: IP65
- Fitting Colour: Charcoal
- Body Material: ABS
- Diffuser Material: Glass
- Installation Type: Surface mount
- Working Temperature Range: -10 to 40 °C
- Input Frequency: 50 Hz
- Maximum Wattage: 9 W
- Input Voltage: 230Vac (216Vac - 253Vac range)
- Input Current: 0.06 A
- Colour Rendering Index (CRI): >80
- LED Type: COB
- CCT Configuration: TRI-CCT (3000K, 4000K, 5000K)
- Macadam Steps: 6-step MacAdam Ellipse
- Beam Angle: 90°
- LED Lifetime: 108,000 hours (L70B10)
- Driver Type: Fixed output, integrated, constant current
- Dimmable: No
- Wiring Type: Re-wireable terminal block (3 pin)
- Sensor Type: PIR with 8 m detection range and 120° detection angle
- Switched Output Rating: 300 W
- Lux Adjustment: Yes
- Manual Override: Yes
- Dusk Mode: Yes
- Adjustable Detection Area / Sensitivity: Yes
- Dimensions (H x L x W): 120mm x 180mm x 150mm
- Weight: 1.2 kg
Key Features
- IP65 rated for weather resistance
- Tri-CCT configuration with Warm White (3000K), Cool White (4000K), and DayLight (5000K) options
- High LED lifetime of 108,000 hours (L70B10 rating)
- PIR sensor with 8m detection range and 120° detection angle
- Fixed output integrated driver with constant current mode
- Non-dimmable
- Re-wireable terminal block (3 pin) for wiring
- Manual override and dusk mode available
- Lux adjustment and adjustable detection area/sensitivity
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended to ensure compliance with electrical standards and optimal sensor functionality.
Applications
- Outdoor security lighting for residential and commercial properties
- Surface mount installation for building exteriors
- Suitable for areas requiring PIR sensor activated lighting
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
- AS/NZS 60598 – Luminaires safety standards (AS/NZS 60598.1 and AS/NZS 60598.2.1)
- AS/NZS 61347 – Lamp control gear (AS/NZS 61347.1 and AS/NZS 61347.2.13)
Environmental Benefits
- High system efficiency of 110 lm/W reduces energy consumption
- Long LED lifetime minimizes waste and replacement frequency
- Fixed output driver optimizes power usage
Warranty Information
Standard 3 years return-to-base warranty. VIP warranty offers 2 years onsite plus 3 years return-to-base (total 5 years) for registered users under specific terms.
Available Now
The Hawk 12W Single LED Security Spotlight by atom is available for immediate purchase, ideal for outdoor security lighting applications requiring durable, sensor-activated illumination.
