HDMI Extender 50m 4K60Hz HDR10 HDCP2.2 Loop Out Matchmaster
Matchmaster 4K HDMI extender over Cat6 features 50m range, HDR10, HDCP 2.2 and IR control. Ideal for home theatres and commercial displays.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Video Resolution: Up to 4K@60Hz 4:4:4, HDR 10
- HDMI Audio Format: LPCM 2ch, LPCM 5.1ch, LPCM 7.1ch, Dolby Digital 2ch, Dolby Digital 5.1ch, DTS 2ch, DTS 5.1ch, DTS 96/24 5.1ch
- Transmission Distance: 4K/1080p ≤ 70 meters (230ft), CATx cable length should be ≥ 15 meters for best output
- HDMI Version: HDMI V2.0
- HDCP Version: HDCP 2.2 compliant
- Power Supply: Input 100VAC~240VAC, 50/60Hz; Output 12VDC 1A
- Power Consumption: 4W (Max)
- Operating Temperature: -25~70°C
- Relative Humidity: 10%-90%
- Input Connectors: 1x 19-pin type-A female HDMI (Source), 1x RJ45 (CATx IN)
- Output Connectors: 1x 19-pin type-A female HDMI (Display), 1x RJ45 (CATx OUT), HDMI loop out port
- Control Connectors: 2x 3.5mm mini jacks for IR IN and IR OUT
- Dimensions (H x L x W): 17mm x 80mm x 80mm
- Weight: 0.5 kg
Key Features
- Extends 4K HDR ultra high definition picture and sound up to 50m using a single CAT6 cable
- HDMI® loop out port for cascading additional extenders or local TV connection
- Copying of EDID signature from either the receiver display or loop out display
- Remote IR control from the extender to a source using supplied IR accessories compatible with pay TV IR remotes
- PoC (Power Over Cable) function requiring only one power supply at the source end
- Supports 4K High Speed HDMI®, HDCP 2.2/HDCP 1.4 and DVI 1.0 compliance
Professional Installation Requirements
- Professional installation by a qualified AV technician or electrician is recommended to ensure optimal performance and compliance with safety standards.
Applications
- Home entertainment systems for extending 4K HDR HDMI signals
- Professional AV installations requiring long-distance HDMI transmission
- Commercial displays and digital signage setups
- Remote IR control applications with pay TV compatibility
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Reduces the need for long HDMI cables, minimizing material waste
- Power Over Cable (PoC) reduces power consumption by using a single power supply
Warranty Information
Standard manufacturer warranty applies. Please refer to Matchmaster warranty policy for details.
Available Now
The Matchmaster 50m 4K High Speed HDMI® Extender Over Cat 6 is available now for immediate purchase. Ideal for home entertainment, professional AV setups, and commercial digital signage requiring high-quality 4K HDMI extension.
