HDMI HDBaseT Extender over Cat6 to 70 Metres, 1080p

HDMI HDBaseT Extender | 70m Range | 1080p & 4K Support | Cat6 by Certech

BRAND: CERTECH

SKU: HDBTEXT70

$321.90 List price: $418.40

+ −

30 Days Return Delivery Options

HDMI HDBaseT extender with 70m range over Cat6 cable, supporting 1080p and 4K resolutions—ideal for home theaters and conference rooms. Built for seamless AV transmission, with bidirectional IR and HDCP compliance.

Description
Attachments

Product Name/Title: HDMI HDBaseT Extender over Cat6 to 70 Metres, 1080p

Brand: Certech

SKU: HDBTEXT70

Alternatively Known As: HDMI Extender, HDBaseT Extender, HDMI over Cat6 Extender

Technical Specifications

HDMI Signal: 4Kx2K, compatible with HDCP, supports CEC & 24 bits deep color.
Supported Resolutions: 480i/480P/576i/576P/720P/1080i/1080P/3D/4Kx2K.
Audio: LPCM, DTS-HD, Dolby True HD.
Network Cable: Cat6/6a.
Transmission Length: Up to 70m for 1080p@60Hz.
Power supply: DC12V/1A *2pcs.
Power consumption: TX < 3.5W, RX < 6W.
Dimensions (H x L x W): 23mm x 98.5mm x 66.5mm
Weight: 0.2 kg

Key Features

Transmits uncompressed HDMI signal over CAT6/6a cable.
Supports full HD 1080p@60Hz, 3D, 4Kx2K@60Hz.
Bidirectional IR pass-back function.
Supports HDCP, CEC, and 24-bit deep color.

Professional Installation Requirements

Professional installation is recommended for optimal performance.

Applications

Residential: Home theater systems
Commercial: Conference rooms, classrooms, digital signage

Standards & Compliance

Complies with AS/NZS 60950 for safety of IT and communication equipment.

Environmental Benefits

Reduces the need for multiple cables, minimizing electronic waste.

Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Certech HDMI HDBaseT Extender over Cat6 to 70 Metres, 1080p is available now for immediate purchase. Ideal for residential and commercial applications.

Specification Sheet (hdbtext70_u.pdf, 250 Kb) [Download]
