Heatshrink Thin Wall 2:1 Ratio 10/5mm Green/Yellow | UV Resistant | Flame Retardant | by Wattmaster
Heatshrink Thin Wall 2:1 Ratio 10/5mm Green/Yellow is perfect for electrical insulation and protection, offering a high tensile strength of 15.5 MPa and a shrink temperature above 110°C. Ideal for heavy-duty applications, this flexible and UV-resistant tubing ensures reliable cable terminations and repairs, making it a must-have for electricians and DIY enthusiasts.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Heatshrink Thin Wall 2:1 Ratio 10/5mm Green/Yellow | UV Resistant | Flame Retardant | by Wattmaster
Brand: Wattmaster
SKU: HSTNW10.0/5.0YG
Alternatively Known As: Heat Shrink Tubing, Heat Shrink Sleeve, Electrical Heatshrink, Cable Insulation Sleeve
Technical Specifications
- Material: Ethylene Vinyl Acetate
- Shrink Ratio: 2:1 (Radial Shrinking Ratio > 50%)
- Shrink Temperature: Above 110°C
- Tensile Strength: 15.5 MPa
- Elongation at Break: 580%
- Longitudinal Shrinking Ratio: 10%
- Colour: Green / Yellow
- Length: 1.2 meters
- Wall Thickness: Thin Wall
- Dimensions (H x L x W): 5mm x 1200mm x 10mm
- Weight: 0.1 kg
Key Features
- Heatshrink suitable for heavy duty and general purpose use
- Material: Ethylene Vinyl Acetate
- Low shrink temperature and flame retardant
- Flexible and UV resistant
- Shrink Temperature above 110°C
- Radial Shrinking Ratio greater than 50%
- Longitudinal Shrinking Ratio of 10%
- High tensile strength of 15.5 MPa
- High elongation at break of 580%
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure proper application and compliance with electrical safety standards.
Applications
- Electrical insulation and protection
- Colour-coding of cables and wires
- Cable terminations and repairs
- General purpose heavy duty electrical applications
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable and reusable insulation reduces waste from cable replacements
- Flame retardant properties enhance safety and reduce fire risk
Warranty Information
Standard manufacturer warranty applies. Please refer to Wattmaster warranty policy for details.
Available Now
Wattmaster Heatshrink Thin Wall 2:1 Ratio 10/5mm Green/Yellow 1.2m is available for immediate purchase, ideal for electrical insulation and cable protection applications.
