Heatshrink Thin Wall Tubing 2.4MM Red | Flame Retardant | Flexible & UV Resistant by Cabac

BRAND: CABAC
SKU: XLP2.5RD-10M
$16.70 List price: $20.30
+
The Cabac Heatshrink Thin Wall 2.4MM Red 10M Box is a flame retardant, flexible heat shrink tubing designed for electrical insulation, protection, and colour coding, suitable for a wide range of electrical applications.

Product Name/Title: Heatshrink Thin Wall 2.4MM Red 10M Box

Brand: Cabac

SKU: XLP2.5RD-10M

Alternatively Known As: Heat shrink tubing, Thin wall heatshrink, Polyolefin heat shrink, Electrical insulation tubing, Red heat shrink sleeve

Technical Specifications
  • Material: Electron Beam Cross Linked Polyolefin
  • Pre-shrink diameter: 2.4mm
  • After-shrink diameter: 1.2mm
  • Recovered wall thickness: 0.48mm
  • Length: 10 meters
  • Continuous Operating Temperature: -75 to +135°C
  • Shrinkage Temperature: > 105°C
  • Longitudinal Shrinkage: < 5%
  • Tensile Strength: 10.4 MPa
  • Breakdown Voltage: 25 kV/mm wall thickness
  • Elongation at Break Point: 400%
  • Water Absorption: 0.15% max
  • Voltage Rating: 600V
  • Heat Shock: 250°C for 4 hours
  • Compliant Standards: UL224 VW1 File No. E366157, ASTM D2671
  • Dimensions (H x L x W): 24mm x 10000mm x 24mm
  • Weight: 0.05 kg
Key Features
  • Flame retardant tubing made from Electron Beam Cross Linked Polyolefin
  • Flexible and resistant to impact and abrasion
  • UV resistant except for clear variants which may fade over time
  • Shrinks to approximately 50% of pre-shrink diameter upon heating
  • Resistant to common fluids and solvents
Professional Installation Requirements
  • Installation should be performed by a qualified electrician using appropriate heat shrinking tools such as a CABAC heat gun (Part No. HG2232 or HG2233) to ensure proper shrinkage and insulation.
Applications
  • Electrical insulation and protection of conductors
  • Colour coding in electrical and associated industries
  • Protection against environmental factors such as fluids and solvents
  • Mechanical protection in electrical installations
Standards & Compliance
  • AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
  • Durable and long-lasting material reduces the need for frequent replacements
  • UV stabilization extends product life, reducing waste
  • Protects electrical components, enhancing energy efficiency and safety
Warranty Information

Standard manufacturer warranty applies. Please refer to Cabac warranty terms for details.

Available Now

The Cabac Heatshrink Thin Wall 2.4MM Red 10M Box is available now for immediate purchase. Ideal for electrical insulation and protection in residential, commercial, and industrial applications.
