Heatshrink Tubing 2.4MM Clear | 200M Reel | Flexible & Impact Resistant by Cabac

BRAND: CABAC
SKU: XLP2.5CL
$56.80 List price: $68.80
Free pick up (over 1 meter)
For delivery quote message
30 Days Return Delivery Options
Heatshrink tubing with 2.4MM diameter and 200M length—ideal for electrical insulation and protection. Built for flexibility and impact resistance, with a clear finish for versatile applications.

Product Name/Title: Heatshrink Thin Wall 2.4MM Clear 200M Reel

Brand: Cabac

SKU: XLP2.5CL

Alternatively Known As: Heat Shrink Tubing, Thin Wall Heatshrink, XLP Heatshrink, Electrical Heatshrink Tubing, Clear Heatshrink Sleeve

Technical Specifications
  • Material: Chemically cross-linked, thermally stabilised flame retardant polyolefin
  • Continuous Operating Temperature: -75°C to +135°C
  • Shrinkage Temperature: >100°C
  • Longitudinal Shrinkage: <5%
  • Tensile Strength: 16 MPa
  • Breakdown Voltage: 25 kV/mm wall thickness
  • Volume Resistivity: 1.0 x 10^14 ohm cm
  • Elongation at Break Point: 400%
  • Water Absorption: 0.15% max
  • Flammability: Passed ASTM-D-2671 (except clear variant which is flammable)
  • Voltage Rating: 600V
  • Compliant Standards: UL224 VW1 File No. E366157
  • Conformant Standards: MIL-1-23053/5 Class 3 (except clear variant Class 2)
  • UV Stability: All tubing stable except clear variant
  • Dimensions (H x L x W): 50mm x 200000mm x 2400mm
  • Weight: 0.5 kg
Key Features
  • Highly flexible
  • Flame retardant except clear variant
  • Abrasion and impact resistant
  • Full range 1.5mm to 125mm diameter with 2:1 shrink ratio
  • Available in most colours on reels or 4ft (1.2m) lengths
  • UV stabilised except clear variant
  • In-house cutting facility available for cut sleeves
Professional Installation Requirements
  • Professional installation recommended to ensure proper shrinking and electrical safety compliance.
Applications
  • Electrical insulation
  • Colour coding of wires and cables
  • Mechanical protection in electrical and electronic applications
Standards & Compliance
  • AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
  • Durable and abrasion resistant, reducing the need for frequent replacements
  • UV stabilised variants extend product life, reducing waste
Warranty Information

Standard manufacturer warranty applies. Please refer to Cabac warranty policy for details.

Available Now

Available for immediate purchase. Ideal for electrical insulation and protection applications in industrial, commercial, and residential settings.
