Pilbara SP 1000Hx800Wx200D IP66 316SS X15

Heavy-Duty Electrical Enclosure | IP66 | 316SS | X15 Finish by B&R Enclosures

BRAND: B&R Enclosures

SKU: SP100822/SRO

$5,359.20 List price: $6,736.00

Free pick up (over 25 kg)

For delivery quote message

30 Days Return Delivery Options

Heavy-duty electrical enclosure with IP66 protection and 316 stainless steel construction—ideal for mining and industrial applications. Built for extreme conditions, with X15 orange powdercoat and flexible mounting options.

Description
Attachments

Product Name/Title: Pilbara SP 1000Hx800Wx200D IP66 316SS X15

Brand: B&R Enclosures

SKU: SP100822/SRO

Alternatively Known As: Pilbara SP Enclosure, Heavy-Duty Electrical Enclosure, Industrial Control Station

Technical Specifications

Protection Rating: IP66
Temperature Range: -10°C to 60°C
Material Options: 2mm zinc coated steel, 1.5mm 316 stainless steel
Surface Finish: ASSDA approved N4 surface finish
Paint Finish: X-15 orange powdercoat
Dimensions (H x L x W): 1000mm x 200mm x 800mm
Weight: 57.9 kg

Key Features

IP66 protection rating
Pintle hinges
Fully enclosed 3-point locking system on most sizes
Provision on door for additional mechanical fixings
Designed to withstand extreme temperatures -10°C to 60°C
Sunshade enclosure options available
30° sloping roof to prevent build up of water and solids
LockSock protective lock cover (IP55)
Easy installation with top and bottom mounting flanges
2mm thick mounting pan mounted on ‘C’ rails
Flexible equipment mounting options
Region D wind rated to AS1170.2-2002

Professional Installation Requirements

Professional installation is recommended to ensure compliance with safety standards.

Applications

Mining: Local control stations
Mineral Processing: Mini control consoles
Infrastructure: Motor isolation control stations

Standards & Compliance

Complies with AS/NZS 61439 for low-voltage switchgear and controlgear assemblies.
Region D wind rated to AS1170.2-2002 for structural design actions.

Environmental Benefits

Durable design reduces the need for frequent replacements, minimizing waste.

Warranty Information

Standard warranty applies, please check with the manufacturer for details.

Available Now

The Pilbara SP Heavy-Duty Enclosure is available now for immediate purchase, ideal for mining and industrial applications.

Specification Sheet (, 439 Kb) [Download]
