Hexagon Bolt DIN 933 | M10 Steel 10.9 | Zinc-Plated & Blue Passivated | @Pack of 25 | by Wurth
Hexagon Bolt DIN 933 in M10 size is crafted from high-strength steel with a property class of 10.9, ensuring secure fastening for mechanical, automotive, and construction applications. The zinc-plated and blue passivated finish provides 48 hours of corrosion protection, making it ideal for various environments. Perfect for professionals seeking reliable and durable fastening solutions.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Hexagon Bolt DIN 933 | M10 Steel 10.9 | Zinc-Plated & Blue Passivated | @Pack of 25 | by Wurth
Brand: Wurth
SKU: 10701035
Alternatively Known As: Hex bolt M10, Hex head bolt, Metric hex bolt, Zinc plated hex bolt, High tensile bolt
Technical Specifications
- Thread type x nominal diameter: M10
- Length: 35 mm
- Head height: 6.4 mm
- External drive: WS17
- Standards: DIN 933 (withdrawn, replaced by ISO 4017)
- Material: Steel
- Property class: 10.9
- Surface: Zinc plated with blue passivation
- Corrosion protection period: 48 hours
- Head type: Hexagon head
- Drive type: Outer hexagon
- Thread type: Metric thread
- Thread form: Standard metric thread
- Thread design: Full thread
- Product class: A
- RoHS-compliant: Yes
- Dimensions (H x L x W): 6.4mm x 35mm x 17mm
- Weight: 0.05 kg
Key Features
- Hexagon head with outer hexagon drive for easy tightening
- Full metric thread design for secure fastening
- Steel material with property class 10.9 for high strength
- Zinc plated with blue passivation providing 48 hours corrosion protection
- RoHS-compliant ensuring environmental safety
Professional Installation Requirements
- Installation by a qualified technician or tradesperson is recommended to ensure proper torque and fastening integrity.
Applications
- Mechanical assembly and fastening
- Automotive repairs and manufacturing
- Construction and structural applications
- Industrial machinery and equipment
Standards & Compliance
- Complies with AS/NZS 1252 for high tensile bolts and fasteners
Environmental Benefits
- RoHS-compliant material reduces hazardous substances
- Durable zinc plating extends product life reducing waste
Warranty Information
Wurth provides standard warranty against manufacturing defects. Please refer to Wurth's warranty policy for details.
Available Now
The Wurth Hexagon Bolt M10x35mm Steel 10.9 Zinc-Plated Blue Passivated DIN 933 - 25 PCS is available now for immediate purchase. Ideal for mechanical, automotive, and construction fastening applications.
