Hexagon Bolt ISO 4017 | Steel 12.9 | Full Thread & Small Cylinder Head | High Load-Bearing Capacity | by WURTH
The Hexagon Bolt ISO 4017 is crafted from durable steel grade 12.9, featuring a full thread up to the head and a small cylinder head design. Ideal for structural wood construction and high-load-bearing applications, this bolt ensures optimal power transmission with its RW drive. Approved for use in indoor dry or wet areas, it supports sustainable building practices while providing reliable performance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Hexagon Bolt ISO 4017 | Steel 12.9 | Full Thread & Small Cylinder Head | High Load-Bearing Capacity | by WURTH
Brand: WURTH
SKU: 00616 50
Alternatively Known As: Hex bolt, Full thread hex bolt, Structural wood bolt, ISO 4017 bolt
Technical Specifications
- Material: Steel grade 12.9
- Thread: Full thread up to the head
- Head type: Small cylinder head
- Drive type: RW drive
- Compliance: Approved according to ETA-11/0190 and ETA-13/0029
- Suitable for indoor dry or wet areas
- Not suitable for direct exposure to elements or chlorine gas atmospheres
- Dimensions (H x L x W): 10mm x 50mm x 10mm
- Weight: 0.1 kg
Key Features
- Full-thread screw with small cylinder head
- High load-bearing capacity
- Ideal power transmission with RW drive
- Suitable for indoor dry or wet areas
- Approved according to ETA-11/0190 and ETA-13/0029
Professional Installation Requirements
- Installation should be performed by qualified personnel using appropriate tools and following WURTH assembly guidelines and software recommendations.
Applications
- Structural wood construction for high-load-bearing wood-wood connections or reinforcements
- Indoor dry or wet areas requiring small edge and screw clearances
- Wood-concrete composite ceilings as per ETA approvals
Standards & Compliance
- AS/NZS 1170 – Structural Design Actions (Wind, Earthquake, Snow Loads)
Environmental Benefits
- Durable steel construction reduces need for frequent replacements
- Supports sustainable wood construction methods
Warranty Information
Warranty against manufacturing defects as per WURTH standard terms and conditions.
Available Now
The WURTH Hexagon Bolt ISO 4017 Steel 12.9 Plain is available for immediate purchase, ideal for structural wood construction and reinforcement applications.
