Hexagon Nut ASME B18.2.2 | GR8 Steel | UNF Fine Thread | @Pack of 25 | by Wurth
Hexagon Nut ASME B18.2.2 made from GR8 steel offers exceptional mechanical strength and durability. With a UNF fine thread design featuring 18 threads per inch, it's perfect for mechanical assemblies and industrial applications. This pack of 25 nuts is ideal for automotive fastening and general-purpose use, ensuring reliable performance in inch-based systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Hexagon Nut ASME B18.2.2 | GR8 Steel | UNF Fine Thread | @Pack of 25 | by Wurth
Brand: Wurth
SKU: 7739363
Alternatively Known As: Hex Nut, Fine Thread Nut, UNF Hex Nut, Inch Hex Nut, GR8 Steel Nut
Technical Specifications
- Nominal diameter: 5/8 inch (15.875 mm)
- Height: 0.559 inch (14.2 mm)
- Width across flats: 15/16 inch (23.81 mm)
- Material: Steel
- Property class: GR8
- Surface finish: Plain
- Thread type: UNF (Unified Fine Thread)
- Threads per inch: 18
- Mechanical properties regulated by SAE J995
- Thread tolerance: ASME B1.1 standard, 2B for internal thread
- Dimensions (H x L x W): 14.2mm x 23.81mm x 23.81mm
- Weight: 0.05 kg
Key Features
- Complies with ASME B18.2.2 standard for hexagon nuts
- Made from GR8 grade steel for high mechanical strength
- UNF (Unified Fine Thread) with 18 threads per inch
- Plain surface finish suitable for various applications
- Thread tolerance according to ASME B1.1 standard (2B for internal thread)
Professional Installation Requirements
- Installation by a qualified technician or engineer is recommended to ensure proper torque and fastening integrity.
Applications
- Mechanical assemblies requiring fine thread hexagon nuts
- Industrial machinery and automotive fastening
- General purpose fastening in inch-based systems
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable steel construction reduces need for frequent replacements
- Recyclable steel material supports sustainable manufacturing
Warranty Information
Standard manufacturer warranty against defects in material and workmanship.
Available Now
Wurth Hexagon Nut in inch size with UNF fine thread is available for immediate purchase, ideal for industrial and mechanical fastening applications.
