Hexagon Nut Imperial | Zinc Plated Steel | GR5 Strength | UNC Thread | @Pack of 25 | by Wurth
Hexagon Nut Imperial made from zinc plated steel offers GR5 strength and UNC threading, making it ideal for mechanical fastening in machinery and automotive assembly. This pack of 25 nuts ensures secure fastening for construction and industrial projects, providing durability and corrosion resistance for long-lasting performance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Hexagon Nut Imperial | Zinc Plated Steel | GR5 Strength | UNC Thread | @Pack of 25 | by Wurth
Brand: Wurth
SKU: 33014
Alternatively Known As: Hex nut, Hexagonal nut, UNC nut, Zinc plated nut, Steel hex nut
Technical Specifications
- Nominal diameter: 1/4 inch (6.35 mm)
- Height: 0.226 inch (5.74 mm)
- Width across flats: 7/16 inch (11.11 mm)
- Material: Steel
- Property class: GR5
- Surface finish: Zinc plated (galvanized)
- Thread type: UNC
- Threads per inch: 20
- Standard: WN 330
- Dimensions (H x L x W): 5.74mm x 11.11mm x 11.11mm
- Weight: 0.02 kg
Key Features
- Galvanized zinc plated steel for corrosion resistance
- Property class GR5 for high strength
- Standard UNC thread with 20 threads per inch
- Comes in pack of 25 pieces
Professional Installation Requirements
- Installation by qualified personnel recommended to ensure proper torque and secure fastening.
Applications
- Mechanical fastening in machinery and automotive assembly
- Construction and structural applications requiring secure fastening
- General purpose fastening in industrial and DIY projects
Standards & Compliance
- Complies with AS/NZS 1170 – Structural Design Actions (Wind, Earthquake, Snow Loads)
Environmental Benefits
- Zinc plating provides corrosion resistance extending product life and reducing waste
Warranty Information
Standard manufacturer warranty against defects applies.
Available Now
Wurth Hexagon Nut imperial 1/4 inch UNC zinc plated steel GR5 pack of 25 is available for immediate purchase, ideal for mechanical and construction fastening applications.
