Hexagon Nut Low Profile M10 | Stainless Steel A4 | Clamping Piece & WS17 Drive | @Pack of 10 | by Wurth
Hexagon Nut Low Profile M10 is crafted from durable stainless steel A4, featuring a clamping piece and WS17 drive for secure fastening. Ideal for mechanical and automotive applications, this nut prevents loosening with its innovative polyamide ring locking mechanism, ensuring reliability in high-vibration environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Hexagon Nut Low Profile M10 | Stainless Steel A4 | Clamping Piece & WS17 Drive | @Pack of 10 | by Wurth
Brand: Wurth
SKU: 39710
Alternatively Known As: Low Profile Hex Nut, DIN 985 Lock Nut, Stainless Steel Locking Nut, M10 Hex Nut with Nylon Insert
Technical Specifications
- Thread type x nominal diameter (D): M10
- Height (m1): 10 mm
- External drive (s1): WS17
- Standards: DIN 985 (withdrawn, replaced by DIN 10511, 10512, 7040)
- Material: Stainless steel A4
- Surface: Plain
- RoHS-compliant: Yes
- Form: Low profile
- Locking device operating principle: Clamping part polyamide ring
- Locking function: Locking against loosening by clamping
- Dimensions (H x L x W): 10mm x 17mm x 17mm
- Weight: 0.05 kg
Key Features
- Hexagon nuts with reduced load capacity and lower nominal height
- Complies with withdrawn DIN 985 standard replaced by DIN 10511, 10512, and 7040
- Locking function achieved by clamping part polyamide ring preventing loosening
- No damage to thread surfaces due to plastic ring locking mechanism
- Operating temperature range from -70°C to +120°C
Professional Installation Requirements
- Installation by qualified personnel recommended to ensure correct torque and locking function.
Applications
- Mechanical fastening in machinery and equipment
- Automotive assembly requiring vibration resistance
- Industrial and construction applications needing secure locking nuts
Standards & Compliance
- AS/NZS 1252 – Mechanical fasteners for general engineering
Environmental Benefits
- Made from stainless steel A4 which is corrosion resistant and durable, reducing replacement frequency and waste
- RoHS-compliant ensuring no hazardous substances are used
Warranty Information
Standard manufacturer warranty against defects applies.
Available Now
Available for immediate purchase, ideal for industrial, automotive, and mechanical fastening applications.
