Hexagonal Bolt ASME B18.2.1 | 316 Stainless Steel | UNC Thread | Plain Finish | @Pack of 5 | by Wurth
Hexagonal Bolt ASME B18.2.1 made from corrosion-resistant 316 stainless steel with UNC thread type and a plain surface finish. Ideal for industrial machinery assembly and marine environments, this bolt ensures durability and compliance with ASME standards, making it perfect for construction and structural fastening applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Hexagonal Bolt ASME B18.2.1 | 316 Stainless Steel | UNC Thread | Plain Finish | @Pack of 5 | by Wurth
Brand: Wurth
SKU: 7004350200
Alternatively Known As: Hex bolt, Stainless steel hex bolt, UNC hex bolt, AISI 316 bolt, Marine grade bolt
Technical Specifications
- Nominal diameter: 1/2 inch
- Length: 2 inch
- Thread type: UNC
- Head height: 0.323 inch
- External drive: WS3/4
- Material: Stainless steel AISI 316
- Surface finish: Plain
- Width across flats: 3/4 inch
- Dimensions (H x L x W): 51mm x 51mm x 19mm
- Weight: 0.05 kg
Key Features
- Hexagonal bolt with UNC thread type
- Made from corrosion-resistant stainless steel AISI 316
- Plain surface finish
- Complies with ASME B18.2.1 and ASTM F593 mechanical properties
- Thread length and dimensions based on ASME B18.2.1 standard
Professional Installation Requirements
- Installation by qualified personnel using appropriate tools is recommended to ensure proper torque and fastening integrity.
Applications
- Industrial machinery assembly
- Marine and chemical environments requiring corrosion resistance
- Construction and structural fastening
- General mechanical fastening applications
Standards & Compliance
- Complies with AS/NZS 4762 for stainless steel fasteners (equivalent to ASTM F593)
Environmental Benefits
- Long-lasting corrosion resistance reduces replacement frequency and waste
- Stainless steel material is recyclable
Warranty Information
Standard manufacturer warranty against defects applies.
Available Now
Available for immediate purchase, ideal for industrial, marine, and construction fastening applications.
