Hexagonal Bolt DIN 933 | M10 Polyamide 6.6 | Full Metric Thread | RoHS Compliant | @Pack of 200 | by Wurth
Hexagonal Bolt DIN 933 in M10 size, crafted from durable polyamide 6.6, is perfect for mechanical and electrical assembly. With a full metric thread design and RoHS compliance, these lightweight fasteners ensure secure fastening and corrosion resistance. Ideal for automotive applications, they provide reliable performance in various environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Hexagonal Bolt DIN 933 | M10 Polyamide 6.6 | Full Metric Thread | RoHS Compliant | @Pack of 200 | by Wurth
Brand: Wurth
SKU: 278031050
Alternatively Known As: Hex bolt M10 polyamide, Nylon hex bolt M10, Plastic hex bolt M10 x 50mm, PA 6.6 hex bolt
Technical Specifications
- Thread type x nominal diameter (d1): M10
- Length (l1): 50 mm
- Head height (k1): 6.4 mm
- External drive (s1): WS17
- Standards: DIN 933 (withdrawn, replaced by ISO 4017)
- Material: PA - Polyamide 6.6
- Surface: Plain
- Head type: Hexagon head
- Drive type: Outer hexagon
- Thread type: Metric thread
- Thread form: Standard metric thread
- Thread design: Full thread
- Product class: A
- RoHS-compliant: Yes
- Dimensions (H x L x W): 6.4mm x 50mm x 17mm
- Weight: 0.05 kg
Key Features
- Hexagon head with outer hexagon drive for easy tightening
- Full metric thread design for secure fastening
- Made from natural polyamide 6.6 for durability and corrosion resistance
- RoHS-compliant material ensuring environmental safety
Professional Installation Requirements
- Installation by a qualified technician or engineer is recommended to ensure proper torque and fastening integrity.
Applications
- Mechanical assembly requiring strong, lightweight fasteners
- Electrical and electronic equipment assembly
- Automotive and machinery applications where corrosion resistance is needed
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems for workplace safety
Environmental Benefits
- Made from polyamide 6.6 which is recyclable and reduces metal corrosion waste
- RoHS-compliant ensuring no hazardous substances are used
Warranty Information
Standard manufacturer warranty applies. Please refer to Wurth warranty policy for details.
Available Now
The Wurth Hexagonal Bolt with thread up to the head DIN 933 Polyamide 6.6 M10 x 50mm 200 PCS is available for immediate purchase. Ideal for mechanical, electrical, and automotive fastening applications.
