HID SIGNO 20 SEOS & ASSA ABLOY ES9000 | Seos Credentials | 1300kg Strength | IP54 Weather Resistant | by Dicker Data
HID SIGNO 20 SEOS & ASSA ABLOY ES9000 is designed for robust access control, featuring Seos credentials support and a 1300kg static strength rating. Ideal for commercial and industrial applications, this weather-resistant unit ensures reliable security with its durable stainless steel construction and high-frequency read range of 4-8 cm. Configurable via the HID Reader Manager App, it meets stringent safety standards for peace of mind.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HID SIGNO 20 SEOS & ASSA ABLOY ES9000 | Seos Credentials | 1300kg Strength | IP54 Weather Resistant | by Dicker Data
Brand: Dicker Data
SKU: TILID4X4-SEOS
Alternatively Known As: HID Signo 20 SEOS Reader, ES9000 Electric Strike, Lockwood ES9000, Electronic Door Strike, Access Control Reader
Technical Specifications
- HID Reader Model: SIGNO 20 SEOS PROFILE
- Supported Credentials: Seos (Mobile ID via NFC/BLE), Seos
- High Frequency Read Range: 4 – 8 cm
- Mounting: Suitable for mullion mount door installation or flat surface mounting
- Keypad Layout: 2x6 Layout Keypad (Bit or buffered mode configurable)
- Controller Communication: Wiegand or RS485 Half Duplex (OSDP) configurable
- Configurable via HID Reader Manager App (iOS and Android)
- Electric Strike Model: ES9000 Lockwood
- Voltage: 10 - 30Vdc
- Current: 250mA @12Vdc, 130mA @24Vdc
- Solenoid: Rated for continuous use
- Electrical Protection: Polarity and back EMF protected
- Monitoring: Solenoid Monitor - 1 amp NO/NC microswitch; Door/Latch Monitor - 1 amp NO/NC microswitch
- Holding Force: 1300kg static strength rating
- Endurance: 1,200,000 cycles @ 25kg pre-load; 2,500,000 cycles general durability
- Latching: Suitable for 15mm latch with 3mm door gap
- Operating Temperature: -20°C to +60°C
- Body Material: Solid Stainless Steel
- Keeper Material: Stainless Steel
- Fire Rating: Up to 4 hours on fire door assemblies per AS1905.1 2005
- Weather Resistance: IP54
- Dimensions (H x L x W): 121.5mm x 21.5mm x 45mm
- Weight: 2.5 kg
Key Features
- Supports Seos credentials including Mobile ID via NFC/BLE
- High frequency read range of 4 – 8 cm
- 2x6 Layout Keypad configurable in Bit or buffered mode
- Configurable with HID Reader Manager App for iOS and Android
- Electric strike with 1300kg static strength rating
- Solenoid rated for continuous use with polarity and back EMF protection
- Monitored solenoid and door/latch with 1 amp NO/NC microswitches
- Solid stainless steel construction with stainless steel keeper
- Fire rated up to 4 hours on fire door assemblies per AS1905.1
- Weather resistant with IP54 rating
- Endurance of 1,200,000 cycles at 25kg pre-load and 2,500,000 cycles general durability
Professional Installation Requirements
- Professional installation by a qualified security systems technician or licensed electrician is required to ensure proper configuration and compliance with safety standards.
Applications
- Access control for commercial and industrial buildings
- Security systems requiring electronic door locking
- Mullion mount door installations or flat surface mounting
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
- Fire rating compliance with AS1905.1 (related to fire & safety standards)
Environmental Benefits
- Durable stainless steel construction reduces replacement frequency
- Energy efficient solenoid operation minimizes power consumption
- Long endurance cycle reduces waste and maintenance needs
Warranty Information
TRICARE® 5 Year Warranty
Available Now
Available for immediate purchase, ideal for commercial and industrial access control and security applications.
