HID Signo 20 STD & ASSA ABLOY ES9000 | IP54 Weather Resistant | 1300kg Holding Force | Multiple Credential Support | by Dicker Data
HID Signo 20 STD & ASSA ABLOY ES9000 is designed for secure access control, featuring IP54 weather resistance and a robust 1300kg holding force. Ideal for commercial and industrial applications, this system supports multiple credential types including Seos, iClass, and MIFARE, ensuring versatile security solutions. With a high-frequency read range of 4 – 8 cm and a durable stainless steel construction, it’s built for reliability and longevity in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HID Signo 20 STD & ASSA ABLOY ES9000 | IP54 Weather Resistant | 1300kg Holding Force | Multiple Credential Support | by Dicker Data
Brand: Dicker Data
SKU: TILID4X4-STD
Alternatively Known As: HID Signo 20 Standard Reader, ES9000 Electric Strike, Lockwood ES9000, Access Control Reader and Strike Bundle
Technical Specifications
- Supported Credentials: Seos (Mobile ID via NFC/BLE), Seos, iClass SE, iClass SR, iClass, MIFARE DESFire EV1/EV2/EV3 (SIO), MIFARE Classic (SIO), MIFARE DESFire EV1 (CSN), MIFARE Classic (CSN), 125kHz HID Proximity, Indala Proximity, EM4102 Proximity
- High Frequency Read Range: 4 – 8 cm
- Mounting: Suited for mullion mount door installation or any flat surface mounting
- Keypad Layout: 2x6 Layout Keypad (Bit or buffered mode configurable)
- Controller Communication: Wiegand or RS485 Half Duplex (OSDP) configurable
- Voltage: 10 - 30Vdc
- Current: 250mA @12Vdc - 130mA @24Vdc
- Solenoids: Rated for continuous use
- Electrical Protection: Polarity and back EMF protected
- Monitoring: Solenoid Monitor - 1 amp NO/NC microswitch, Door / Latch Monitor - 1 amp NO/NC microswitch
- Holding Force: 1300kg static strength rating
- Endurance: 1,200,000 cycles endurance rating @ 25kg pre-load, 2,500,000 cycles general durability without pre-load
- Latching: Suitable for 15mm latch with 3mm door gap
- Environment: Operational temperature range -20°C to +60°C
- Body: Solid Stainless Steel Construction
- Keeper: Stainless Steel
- Fire Rated: Successfully fire rated up to 4hrs on fire door assemblies in accordance with AS1905.1. 2005
- Weather Resistant: IP54
- Dimensions (H x L x W): 21.5mm x 121.5mm x 45mm
- Weight: 2.5 kg
Key Features
- Supports multiple credential types including Seos, iClass, MIFARE, and proximity cards
- High frequency read range of 4 – 8 cm
- Configurable 2x6 layout keypad with bit or buffered mode
- Controller communication via Wiegand or RS485 Half Duplex (OSDP)
- Configurable with HID Reader Manager App for iOS and Android
- ES9000 Lockwood electric strike with 25kg pre-load monitored multi-functional operation
- Solenoid rated for continuous use with polarity and back EMF protection
- Monitoring with 1 amp NO/NC microswitches for solenoid and door/latch
- 1300kg static strength rating and 1,200,000 cycles endurance at 25kg pre-load
- Solid stainless steel construction with IP54 weather resistance
- Fire rated up to 4 hours on fire door assemblies per AS1905.1. 2005
- Operational temperature range from -20°C to +60°C
Professional Installation Requirements
- Professional installation by a qualified security systems technician or licensed electrician is recommended to ensure compliance with safety and fire regulations.
Applications
- Access control for commercial and industrial buildings
- Security door installations requiring electronic locking
- Mullion mount door installations or flat surface mounting
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
- Fire rated in accordance with AS1905.1. 2005 (Part 1: Fire resistant door sets)
Environmental Benefits
- Durable stainless steel construction reduces replacement frequency and waste
- Energy-efficient solenoid rated for continuous use minimizes power consumption
- Weather resistant IP54 rating ensures long product life in various environments
Warranty Information
TRICARE® 5 Year Warranty
Available Now
The HID SIGNO 20 STD X 4 & ASSA ABLOY ES9000 X 4 Tap In & Lock It Down Promotion is available now for immediate purchase. Ideal for secure access control installations in commercial and industrial environments.
