HID Signo 40K Keypad Black Reader | Supports Mobile Credentials | Configurable Keypad Layout | 25-Year Warranty | by Dicker Data
The HID Signo 40K Keypad Black Reader is designed for secure access control, supporting a wide range of credential technologies including mobile IDs via NFC/BLE. With a configurable 3x4 keypad layout and professional installation recommended, it's perfect for commercial buildings and restricted areas, ensuring reliable security and ease of use.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HID Signo 40K Keypad Black Reader | Supports Mobile Credentials | Configurable Keypad Layout | 25-Year Warranty | by Dicker Data
Brand: Dicker Data
SKU: 40KNKS-00-000000
Alternatively Known As: HID Signo Keypad Reader, HID 40K Keypad Reader, HID Signo Access Control Reader
Technical Specifications
- Supported Credentials: Seos (Mobile ID via NFC/BLE), Seos, iClass SE, iClass SR, iClass, MIFARE DESFire EV1/EV2/EV3 (SIO), MIFARE Classic (SIO), MIFARE DESFire EV1 (CSN), MIFARE Classic (CSN), 125kHz HID Proximity, Indala Proximity, EM4102 Proximity
- High Frequency Read Range: 4 – 10 cm
- Mounting: Suitable for mullion mount door installation or any flat surface mounting
- Keypad Layout: 3x4 Layout Keypad (Bit or buffered mode configurable)
- Controller Communication: Wiegand or RS485 Half Duplex (OSDP) configurable
- Configuration: Configurable with HID Reader Manager App (iOS and Android)
- Dimensions (H x L x W): 121.5mm x 19.5mm x 80mm
- Weight: 0.2 kg
Key Features
- Supports a wide range of credential technologies including cards, fobs, and mobile devices
- 3x4 layout keypad with bit or buffered mode configurable
- Configurable with HID Reader Manager App for iOS and Android
- Suited for mullion mount door installation or any flat surface mounting
Professional Installation Requirements
- Professional installation by a qualified security systems technician or electrician is recommended to ensure proper configuration and secure mounting.
Applications
- Access control for commercial buildings
- Multi-factor authentication door systems
- Secure entry for offices and restricted areas
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Supports mobile credentials reducing the need for physical cards and fobs
- Energy-efficient design for reduced power consumption
Warranty Information
25 years warranty.
Available Now
The HID Signo 40K Keypad Black Reader Standard Profile Pigtail 25YR is available now for immediate purchase. Ideal for secure access control in commercial and institutional environments.
