HID U90 Long Range Reader | UHF 902-928 MHz | IP65 Rated | Hands-Free Authentication | by HID Global
The HID U90 Long Range Reader operates on UHF 902-928 MHz, providing discreet hands-free authentication for secure parking and gate control. With an IP65 rating, it’s built to withstand harsh environments, making it ideal for vehicle identification and integration with building access systems. This reader supports UHF ISO 18000-6C compliant credentials, ensuring secure end-to-end communications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HID U90 Long Range Reader | UHF 902-928 MHz | IP65 Rated | Hands-Free Authentication | by HID Global
Brand: HID Global
SKU: RDRSEU909K0000
Alternatively Known As: HID U90 UHF Long Range Reader, iCLASS SE UHF Reader, HID Long Range Access Reader
Technical Specifications
- Transmit Frequency: 865 - 868 MHz / 902 - 928 MHz depending on region
- Typical Maximum Read Range: Up to 5 meters depending on installation and vehicle windshield
- Input Voltage: 12VDC or 24VDC
- Current: 1A @ 12Vdc / 0.5A @ 24Vdc Peak
- Cable Length: Wiegand = 152 m (22 AWG) / 91 m (24 AWG)
- Housing: UL94 Polycarbonate
- Operating Temperature: -35° to 65°C
- Operating Humidity: 5% to 95% non-condensing
- Environmental Rating: IP65
- Card Compatibility: UHF EPC Class 1 Gen 2, ISO 18000-6C
- Security: EAL5+ certified crypto-processor hardware
- Dimensions (H x L x W): 70mm x 231mm x 231mm
- Weight: 1.2 kg
Key Features
- Discreet hands-free authentication for long range parking and gate control
- Field configurable via a full user interface for ease of maintenance
- Supports UHF ISO 18000-6C compliant credentials with Secure Identity Object (SIO) encryption
- Encryption of card data through controller for secure end-to-end communications
Professional Installation Requirements
- Installation by a qualified security systems technician or licensed electrician is recommended to ensure proper configuration and compliance with safety standards.
Applications
- Parking access control
- Gate control systems
- Vehicle identification and secure entry
- Integration with building access control systems
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Supports secure access control reducing unauthorized vehicle entry and improving energy efficiency in facility management
- Durable IP65 rated housing reduces need for frequent replacements
Warranty Information
Standard manufacturer warranty applies; typically 2 years against defects.
Available Now
The HID U90 Long Range Reader iCLASS SE Rev E UHF 902-928 MHz is available for immediate purchase, ideal for secure parking and gate access control applications.
