Trade Discount 25%
High Current Socket Outlet 90A | IP66 Rated | 1P+N+E | 250V AC by NHP
High current socket outlet with 90A capacity and IP66 rating—ideal for industrial and commercial applications. Built for heavy machinery and equipment, with durable polyamide construction for long-lasting performance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: PROCONECT 3PS63 Socket Outlet, 1P+N+E, 90A (AC23 63A) 250V AC
Brand: NHP
SKU: 3PS6D1NE01
Alternatively Known As: High Current Socket Outlet, 90A Socket, Industrial Socket Outlet
Technical Specifications
- Amperage: 90 A
- Voltage: 220-240 V
- Contact Configuration: 1P+N+E
- Construction Type: Outlet
- Material Insulation Body: Polyamide (PA)
- Contact Material: Other
- Material Screw: Stainless steel
- Degree of Protection: IP66
- Nominal Tightening Torque: 4 Nm
- Operating Temperature: -30-60 °C
- Dimensions (H x L x W): 100mm x 115mm x 100mm
- Weight: 0.64 kg
Key Features
- High current capacity of 90A for demanding applications.
- IP66 rated for protection against dust and water ingress.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Heavy machinery and equipment
- Commercial: Workshops, factories, and construction sites
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installation safety.
Environmental Benefits
- Durable materials reduce the need for frequent replacements, minimizing waste.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The PROCONECT 3PS63 Socket Outlet is available now for immediate purchase. Ideal for industrial and commercial applications requiring high current connectivity.
