High Precision Standard Sensor | RGB LED Light Source | IP67 Rated | by SICK
The High Precision Standard Sensor is designed for industrial automation, featuring a sensing distance of up to 13 mm and an RGB LED light source with wavelengths of 470 nm, 525 nm, and 625 nm. With a fast response time of 3 µs and IP67 protection, this sensor is perfect for high precision object detection and machine safety applications, ensuring reliable performance in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Sensing distance: ≤ 13 mm with ±5 mm tolerance
- Light source: LED RGB with wavelengths 470 nm, 525 nm, 625 nm
- Light emission: Long side of housing with 0.9 mm x 3.8 mm spot size
- Supply voltage: 10.8 V DC to 28.8 V DC with ≤ 5 V ripple
- Current consumption: < 100 mA
- Switching frequency: 70 kHz
- Response time: 3 µs
- Output: Push-pull PNP/NPN, max output current 100 mA
- Protection class: III with reverse polarity and short-circuit protection
- Connection: Plug, M12, 5-pin
- Operating temperature: -20 °C to +60 °C
- Storage temperature: -25 °C to +75 °C
- Enclosure rating: IP67
- Shock resistance: 30 g/11 ms per IEC 60068-2-27
- Dimensions (H x L x W): 62mm x 48mm x 26mm
- Weight: 0.1 kg
Key Features
- High precision sensing with a sensing distance up to 13 mm
- LED RGB light source with wavelengths of 470 nm, 525 nm, and 625 nm
- Light/dark switching output function with adjustable delay time
- Robust housing made of VISTAL® with COP optics material
- IP67 rated enclosure for protection against dust and water
- Fast response time of 3 µs and switching frequency of 70 kHz
- Push-pull PNP/NPN switching output with short-circuit protection
- Multiple teach-in modes including 1-point, 2-point, dynamic, and auto
- Shock load resistance according to IEC 60068-2-27 (30 g/11 ms)
- Non-volatile memory with 25 ms retention time for teach-in settings
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with electrical and sensor device standards to ensure proper setup and safety compliance.
Applications
- Industrial automation and control
- High precision object detection
- Machine safety and monitoring
- Robotics and manufacturing processes
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Energy-efficient LED light source reduces power consumption
- Durable IP67 housing extends product lifespan, reducing waste
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Warranty details available upon request from SICK; typically includes coverage against manufacturing defects.
Available Now
The SICK KTS-WB91141152ZZZZ sensor is available for immediate purchase, ideal for high precision industrial sensing and automation applications.
