High Pressure Sensor | 0 to 1000 Bar Gauge Pressure | IP67 Rated | Stainless Steel Housing | by SICK
The High Pressure Sensor measures gauge pressure from 0 to 1000 bar, making it ideal for industrial process monitoring of liquids and gases. With a fast response time under 4 ms and high accuracy of ≤ ±0.5% span, this robust sensor features a durable stainless steel housing and an IP67 rated enclosure for dust and water protection, ensuring reliable performance in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Measuring range: 0 bar to 1000 bar gauge pressure
- Process temperature: 0 °C to +80 °C
- Output signal: 0 V to 10 V, 3-wire
- Supply voltage: 14 V DC to 30 V DC
- Power consumption: Max 8 mA for voltage output
- Electrical safety: Overvoltage protection 32 V DC, short-circuit and reverse polarity protection
- Enclosure rating: IP67
- Process connection: G ½ A (ISO 1179-2)
- Wetted parts: 316L stainless steel
- Response time: < 4 ms
- Accuracy: ≤ ±0.5% of span
- Non-linearity: ≤ ±0.25% of span
- Hysteresis: ≤ 0.16% of span
- Non-repeatability: ≤ 0.1% of span
- Long-term drift: ≤ 0.1% of span per year
- Shock load: 500 g
- Vibration load: 10 g standard, 20 g optional
- Dimensions (H x L x W): 70mm x 30mm x 30mm
- Weight: 0.1 kg
Key Features
- Measures gauge pressure from 0 bar to 1000 bar
- Suitable for liquid and gaseous media
- High accuracy with ≤ ±0.5% span including non-linearity and hysteresis
- Fast response time under 4 ms
- Robust stainless steel housing and wetted parts (316L stainless steel)
- IP67 rated enclosure for dust and water protection
- Overvoltage, short-circuit, and reverse polarity protection
- Long service life with minimum 100 million load cycles
- M12 round 4-pin connector for electrical connection
- Operating temperature range 0 °C to +80 °C
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with electrical safety standards.
Applications
- Industrial process monitoring of liquid and gaseous media
- Hydraulic and pneumatic systems requiring precise pressure measurement
- Automation systems needing reliable gauge pressure sensing
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable stainless steel construction reduces waste and extends product life
- Low power consumption enhances energy efficiency
- Long service life minimizes replacement frequency and material waste
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK PBT-RB1K0AGTSSNVMC0Z pressure sensor is available for immediate purchase, ideal for industrial and automation applications requiring precise high-pressure measurement.
