High Speed Fuse 500A 690V AC | Class aR | Dual Indicator | DIN 3 by Eaton
High speed fuse rated at 500A and 690V AC, designed for rapid circuit interruption—ideal for industrial electrical protection. Built for sensitive electronic equipment, with a dual indicator for easy status monitoring.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: High Speed Fuse 500A 690V AC | Class aR | Dual Indicator | DIN 3 by Eaton
Brand: Eaton
SKU: 170M6808D
Alternatively Known As: High Speed Fuse 500A, aR Fuse Link, DIN 3 Fuse, Eaton Bussmann High Speed Fuse
Technical Specifications
- Amperage Rating: 500 A
- Voltage Rating: 690 V AC (IEC), 700 V (UL)
- Breaking Capacity: 200 kA
- Clearing (I2T): 99500 at 660 V
- Pre-arc (I2T): 14000
- Watt Losses: 43 W
- Fuse Size: 3
- Class: aR
- Fitted with: Dual indicator
- Certifications: IEC Rated, UL Recognized
- Compliances: CE Marked, RoHS Compliant
- Dimensions (H x L x W): 87mm x 150mm x 71mm
- Weight: 1.108 kg
Key Features
- High speed fuse-link for rapid circuit interruption
- Rated at 500 A and 690 V AC
- Class aR fuse for semiconductor protection
- Dual indicator for fuse status
- Live gripping lugs for safe handling
- Complies with IEC and UL standards
Professional Installation Requirements
- Installation must be performed by a qualified electrician to ensure compliance with safety standards and proper fuse operation.
Applications
- Industrial electrical protection
- High-speed circuit interruption in electrical systems
- Protection of sensitive electronic equipment
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- RoHS compliant, reducing hazardous substances
- CE marked ensuring compliance with environmental and safety standards
Warranty Information
Standard Eaton warranty applies; please refer to Eaton's official warranty policy for details.
Available Now
The Eaton FUSE 500A 690V aR DIN 3 HSDNH is available for immediate purchase, ideal for industrial and commercial electrical protection applications.
