High Speed Fuse 80A 690V AC | 200 kA Breaking Capacity | Class aR Design | Dual Indicator by Eaton
High speed fuse rated for 80A and 690V AC, featuring a 200 kA breaking capacity and dual indicator for easy monitoring. Ideal for industrial and commercial electrical systems, it ensures reliable protection for sensitive equipment and power distribution panels.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: High Speed Fuse 80A 690V AC | 200 kA Breaking Capacity | Class aR Design | Dual Indicator by Eaton
Brand: Eaton
SKU: 170M1566D
Alternatively Known As: High Speed Fuse 80A, 690V aR Fuse, DIN 000 Fuse, Bussmann Square Body Fuse
Technical Specifications
- Amperage Rating: 80 A
- Voltage Rating: 690 V (IEC), 700 V (UL)
- Voltage Type: AC
- Breaking Capacity: 200 kA
- Class: Class aR
- Fuse Size: 000
- Clearing (I2T): 2700 at 660 V
- Pre arc (I2T): 380
- Watt Losses: 15 W
- Fitted with: Dual indicator
- Certifications: IEC Rated, UL Recognized
- Compliances: CE Marked, RoHS Compliant
- Dimensions (H x L x W): 51mm x 79mm x 21mm
- Weight: 0.136 kg
Key Features
- High speed square body fuse design
- Rated for 80A and 690V AC (IEC) operation
- Breaking capacity of 200 kAIC
- Combination fuse status indicator for easy monitoring
- Class aR fuse for semiconductor protection
- Dual indicator fitted for fuse status
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical safety standards and proper fuse operation.
Applications
- Electrical protection in industrial and commercial electrical systems
- High-speed circuit interruption for sensitive equipment
- Use in power distribution panels and control systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- RoHS compliant, reducing hazardous substances
- CE marked ensuring compliance with environmental and safety standards
Warranty Information
Standard Eaton warranty applies; typically 1 year against manufacturing defects.
Available Now
The Eaton Bussmann Series High Speed Square Body Fuse 80A 690V aR DIN 000 HSDNH is available for immediate purchase, ideal for industrial and commercial electrical protection applications.
