Hioki Clamp Meter 1000A AC | CAT IV 300V | Flex Input
Hioki clamp meter with 1000A AC capacity and CAT IV 300V rating—ideal for electrical diagnostics. Built for versatility, with a compact design and optional flexible sensor for tight spaces.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Hioki Clamp Meter 1000A AC | CAT IV 300V | Flex Input
SKU: 3280-10F
Alternatively Known As: Hioki 3280-10F Clamp Meter, Hioki AC Current Clamp Meter, Flexible Clamp Meter, Hioki 1000A Clamp Meter
Technical Specifications
- Measurement Method: Average rectified method
- Current Measurement: 1000A AC standard, up to 4199A with flexible sensor
- Operating Temperature Range: -25°C to 65°C
- Safety Ratings: CAT IV 300V (Current), CAT III 600V (Current), CAT III 300V (Voltage), CAT II 600V (Voltage)
- Drop Proof: Withstands 1 meter drop
- Dimensions (H x L x W): 180mm x 40mm x 70mm
- Weight: 0.5 kg
Key Features
- Measures fundamental waveform component using average rectified method
- Expanded operating temperature range from -25°C to 65°C
- Optional CT6280 flexible sensor for measuring up to 4199 A in thick or paired wires
- Drop proof design withstands drops from 1 meter height
Professional Installation Requirements
- Professional use recommended; installation or use by qualified electrical personnel advised for safety and accuracy.
Applications
- Electrical maintenance and troubleshooting
- Industrial and commercial electrical inspections
- Measurement of current in tight or hard-to-reach spaces
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Enables precise current measurement to optimize energy usage and reduce waste
- Durable design reduces need for frequent replacements
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Hioki Clamp Meter 1000A AC CAT IV 300V with Flex Input is available now for immediate purchase. Ideal for electrical professionals requiring accurate current measurement in industrial and commercial settings.
