HL18-L1G2AG | Photoelectric sensors
The SICK HL18-L1G2AG is a durable photoelectric retro-reflective sensor featuring a dual lens system, visible red PinPoint LED light, and adjustable sensitivity, ideal for precise object detection in industrial automation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HL18-L1G2AG | Photoelectric sensors
Brand: SICK
SKU: 1088839
Alternatively Known As: Photoelectric sensor, Retro-reflective sensor, M18 photoelectric sensor, Industrial object sensor
Technical Specifications
- Functional principle: Photoelectric retro-reflective sensor with dual lens system
- Sensing range: 0.03 m to 6.5 m
- Light source: PinPoint LED, visible red light, wavelength 631 nm
- Supply voltage: 21.6 V DC to 250 V DC, 96 V AC to 250 V AC
- Current consumption: ≤ 10 mA
- Switching output: MOSFET, light switching mode
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1,000 Hz
- Time functions: Off delay adjustable 0 to 2 seconds
- Connection type: Cable open end, 2,000 mm, PVC cable
- Protection class: II
- Enclosure rating: IP67, IP69K
- Housing material: Plastic VISTAL®
- Optics material: Plastic PMMA
- Operating temperature: –40 °C to +70 °C
- Storage temperature: –40 °C to +75 °C
- EMC compliance: EN 60947-5-2
- Dimensions (H x L x W): 45.5mm x 34.4mm x 16.2mm
- Weight: 0.1 kg
Key Features
- Photoelectric retro-reflective sensor with dual lens system for minimum distance to reflector
- Visible red light with PinPoint LED light source
- Sensing range from 0.03 m to 6.5 m
- Adjustable sensitivity and off delay potentiometers
- MOSFET switching output with light switching mode
- High switching frequency of 1,000 Hz and response time ≤ 0.5 ms
- Robust plastic VISTAL® housing with IP67 and IP69K protection ratings
- Wide ambient operating temperature range from –40 °C to +70 °C
- Cable open end connection with 2,000 mm PVC cable
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper sensor alignment and electrical connection according to industrial safety standards.
Applications
- Industrial automation for object detection
- Material handling and conveyor systems
- Safety and monitoring in manufacturing processes
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Low power consumption with efficient MOSFET switching output
- Durable IP67/IP69K rated housing reduces waste by extending product lifespan
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK HL18-L1G2AG Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
